Driving Type
Adult
Charging Cut-off Voltage
14.6V
Discharging Cut-off Voltage
8.0V
Housing Material
Metal Shell
Weight
22kg
Cycle Life
Over 3000 Times
Max Charging Current
100A
Max Discharging Current
100A
Operation Temperature
-20c to 60c
Applications
Solar Storage System, RV, Boat, Solar Street
Months Self Discharge
<3%
Terminal
M8
Delivery Time
10-15days(Samples);25-30days(Bulk Order)
OEM/ODM
Acceptable
Customize Battery
Available
Transport Package
Standard Air Transport Packaging
Specification
12.8V 200Ah 2560Wh
Trademark
HWE
Origin
China
HS Code
850760009
Production Capacity
10000 Piece/Pieces Per Month
After-sales Service:
3 Years
Warranty:
1 Year
Certification:
RoHS, ISO 9001:2000, ISO 9001:2008, CE
Usage:
Cargo And Passenger
Wheel Distance:
1100mm
Battery:
Lithium-Ion Battery
Prouduct Description
Solar Storage System Battery Rechargeable lithium 12V 100ah Lifepo4 Battery for RV/EV/Backup/golfcart
| Electrical Characteristics | Nominal Voltage | 12.8v |
| Nominal Capacity | 200Ah | |
| Energy | 2560Wh | |
| Maximum Modules In Series | 4 | |
| Cycle Life | >3000 cycles @ 1C 100% DOD | |
| Months Self Discharge | <3% | |
| Effciency of Charge | 100%@0.5C | |
| Effciency of Discharge | 96-99%@1C | |
| Standard Charge | Charge Cut-off Voltage | 14.6±0.1V |
| Charge Mode | 0.2C to 14.6V,then 14.6V,charge current to 0.02C(CC/CV) | |
| Charge current | 100A | |
| Max charge current | 100A | |
| Standard Discharge | Continuous current | 100A |
| Max pulse current | 200A(<3s) | |
| Discharge Cut-off Voltage | 8V | |
| Environmental | Charge Temperature | 0 ºC to 45 ºC (32F to 113F) @60±25% Relative Humidity |
| Discharging Temperature | -20 ºC to 80 ºC (-4F to 140F) @60±25% Relative Humidity | |
| Storage Temperature | 0 ºC to 40 ºC (32F to 104F) @60±25% Relative Humidity | |
| Mechanical | Plastic Case | Metal shell |
| Dimension | 522*238*218/220mm | |
| Terminal | M8 | |
| Weight | 22kg |
Features of LiFePO4 Battery (12V 200ah Lifepo4 battery)
Solar Storage System Battery Rechargeable lithium 12V 200ah Lifepo4 Battery for RV/EV/Backup/golfcart
1,Longer Cycle Life:Offers up to 20times longer life and five times longer fioat life than lead acid battery, helping to minimize replacement cost and reduce total cost of ownership.
2,Lighter Weight:About 40% of the weight of a comparable lead acid battery. A 'drop in' replacement for lead acid batteries.
3,Higher Power:Delivers twice power of lead acid battery,even high discharging rate,while maintaining high energy capacity.
4,wider Temperature Range:-20ºC-60ºC.
5,Superior Safety:Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact,overcharging or short circuit situation.
6,Increased Flexibility:Modular design enables deployment of up to four batteries in series and up to batteries in parallel.
