Great Performance Farm Tractor 120HP Garden Tractor Lt1204 with Powerful Engine
1. Adopt diesel engine, good reliability, large reserves of torque, low fuel consumption, high economic efficiency;
2. Double-function clutch, 13 inches, high transmission capacity, reliable, comfortable manipulation;
3. Gearbox using 4 × (3 +1) engaging sleeve gearshift , there are 12forward gears, 4 reverse gears, reasonable match between the gears, and have high efficiency;
4. Independent power take off device, smooth transmission, large capacity;
5. Using an independent circuit of hydraulic steering control system, manipulating flexible, reliable, and save energy;
6. Adopt hydrostatic disc-type brakes, a large braking torque, the braking effect is good;
7. Adopt high pressure type lifting device, reliable, easy maintenance, multi-hydraulic output can be optioned;
8. Final transmission adopts planetary gear mechanism, compact structure, large reduction ratio;
9. New streamlined appearance, generous, modern, fashion;
Tractor Model | LT1204 | LT1254 | LT1304 | |
Drive Type | 4×4 | |||
Overall Dimension L×W×H(mm) | 5040×2255×2870 | 5050×2370×3000 | ||
Wheel base(mm) | 2688.5 | |||
Front wheel tread(mm) | 1672-2003(1760) | 1822-2153(1910) | ||
Rear wheel tread(mm) | 1662-2262(1662) | 1662-2262(1662) | ||
Min. ground clearance(mm) | 470 | |||
Min. steering radius (m) | 7 | |||
Min. operating weight(KG) | 4850 | 4810 | ||
Gearbox gears number | 12F+4R | |||
Speed | Forward(Kw/h) | 2.19-29.63 | ||
Reverse(Kw/h) | 4.72-13.83 | |||
Engine | Model | LR6B5-23 | LR6M5-23 | LR6M5-23 |
Rated power (Kw) | 88.2 | 92 | 95.6 | |
Type | 6 cylinders, in line, water cooling, 4 strokes, direct injection, natural aspiration | |||
Rated speed(r/min) | 2300 | |||
Tires spec. | Front tires | 14.9-26 | ||
Rear tires | 18.4-38 | |||
Steering type | Full hydraulic front wheels steering | |||
Max. lifting force( KN ) | ≥28 | |||
PTO | Type | Rear-mounted, Independent type | ||
Speed (r/min) | 540/1000 | |||
Power(Kw) | 71.25 | 78.85 | 81.7 | |
Control type of ploughing depth | Height control & flotation control | |||
Max. traction force (KN) | 27 | 29 | 32 | |
Front / Rear ballast (KG) | 500/300 | 600/400 | ||
