Model NO.
TL604
Usage
Farm Tractor
Certification
ISO, CE, CCC, ISO/TS16949, EEC, XQC
Drive Wheel
4WD
Emission Standard
Euro II
Fuel
Gas / Diesel
Service Life
3-6 Years
Size
Small
Color
Green
Condition
New
Product Range
20HP-220HP
Product Name
Garden Diesel 50HP 60HP 70HP 4WD Farm Tractor Wit
Engine Brand
Yto/Yunnei
Use
Agriculture
Transport Package
Wooden Package
Specification
TL604
Trademark
TAVOL
Origin
China
HS Code
8701931000
Production Capacity
2000sets/Year
After-sales Service:
Free Accessories
Warranty:
1 Year
Type:
Wheel Tractor
Mini Compact Garden Diesel 50HP 55HP 60HP 70HP 80HP 4WD Farm Tractor with Front Loader Power Tiller
Feature:
We Cooperate with Domestic Well-known Brand Tractor Parts Suppliers, such as: Gearboxes are Assembled by Ourselves, the Gears Inside are Made of Hangzhou Gears brand, the Bearings are Harbin Brand, the Engines are Xichai, Yuchai or YTO brand, and the Clutches are YTO ZC brand, the Hood and Cab is Equipped with Zhongyuan Brand, and the Tires use Taishan Or Xulun Brand etc.
Advantage:
Advantage:
Good Tractor Accessories Ensure the Quality of Tavol Tractor. Therefore, We Promise to Provide 24 Months of Quality Assurance and After-sales Service for the Whole Machine.
Benefit:
Benefit:
The Perfect Product Quality Control System Allows You to Buy with Confidence, to Operate Without Worry, and to Create Greater Value for Your Farmland Sowing and Harvest Operations.
| Tavol 60hp Tactor Main Parameters | |||
| Model | TL604 | ||
| Type | 4x4 | ||
| Machine parameters | PTO power (KN) | 37.6 | |
| Rated Traction( KN) | 16.2 | ||
| Dimensions(mm) | 3560×1650×2350 | ||
| Wheelbase(mm) | 1965 | ||
| Track(mm) | Front wheel | 1150 | |
| Rear wheel | 1200-1360 | ||
| Minimum ground clearance(mm) | 330 | ||
| Turning circle radius | Unilateral braking | 2.7±0.20,2.85±0.20 | |
| Not unilateral braking | 3.0±0.30,3.15±0.30 | ||
| Weight (KG) | 1828 | ||
| Drive Train | Clutch | Single or dual stage cluth | |
| Gearbox | 8+2 shift/8+8 shuttle shift | ||
| Walking steering | Tire | Front wheel | 6.00-16/6.5-16/7.5-16 |
| Rear wheel | 9.4-24/11.2-24/12.4-24/12.4-28 | ||
| Braking system | Service brake | Shoe brake | |
| Working equipment | Maximum lifting force at 610mm(KN) | 8.3 | |
| Suspension mechanism | Three-point suspension type 1 | ||
| Hydraulic output | Optional 1 or 2 groups | ||
| PTO shaft | PTO speed r/min | 540/760 or 760/1000 | |
| Engine | Engine brand | Laidong | |
| Engine type | Diesel engine | ||
| Engine cylinder | 4 | ||
| Optional | Cabin | AC | |
| Start | Start method | Electric | |
| Main fill volume | Radiater | 10 | |
| Fuel tank | 29 | ||
| Engine oil pan(L) | 5 | ||
| Driveline oil (L) | 20 | ||
| Lifter(L) | 9.5 | ||
| This parameter table is for reference only, everything is based on actual products | |||
*Advantages:
* The 4-post cabin allows the driver to have a wider field of vision.
* The 4-post cabin allows the driver to have a wider field of vision.
* Flat floor design is free and comfortable.
* Steering
wheel with direction ball makes it easier to operate.
wheel with direction ball makes it easier to operate.
* Shuttle shift makes forward and backward clear at a glance.
* Shock absorption seats, driving on bumpy roads will not have too much shock.
*Engine
* 4 cylinder turbocharged diesel engine, Powerful and easy to maintain.
* Could choose china famous brand engine, Xichai, YTO, Xinchai etc.
* 4 cylinder turbocharged diesel engine, Powerful and easy to maintain.
* Could choose china famous brand engine, Xichai, YTO, Xinchai etc.
* Low fuel consumption and large torque reserve.
* Cooling system effectively reduce engine temperature.
* Cooling system effectively reduce engine temperature.
*3 Point Linkage
Can be replaced according to the customer actually want to use agricultural machinery and tools
Can be replaced according to the customer actually want to use agricultural machinery and tools
*Lifter
* Hydraulic lifter, greater lifting force, the downward pressure is more powerful, which can better press agricultural machinery into the soil.
* Hydraulic lifter, greater lifting force, the downward pressure is more powerful, which can better press agricultural machinery into the soil.
* 2 groups hydraulic output, can be connected to agricultural machinery using hydraulic oil.
* 3-point lift power 1050kg.
* 3-point lift power 1050kg.
Cabin Color according to customers' need
Optional CKD&SKD Package/ Full & Farm containers
Tavol Group is a High-tech Groups Companies, Which Engage in High-end Agricultural Equipment Manufacturing, Construction Machinery and High-precision Monitoring Sensors. Tavol Group is Located at the Foot of the World-famous Mountain Taishan. Has Passed ISO9001, CE, SGS, BV, AAA, WIPO Madrid International Trademark, High-tech Enterprise Certification and Special Equipment Manufacturing License etc.
Shandong Tavol Agricultural Machinery Co., Ltd. Is Focused on Development Of the Characteristic Agricultural Machinery, Like Paddy Fields, Mountains, Hills etc; High-end Intelligence, Like Unmanned Driving and Beidou Precision Agriculture; also Automation like CVT and Power Gear Shift etc. Products range: 25hp-280hp Farm Tractors and Other Farm Machines.
The Mission of Tavol Group is to Assemble the Best Tractors With the Best of Heart, and Strive for the Smiles of One billion Farmers; With the Values of Tolerance, Openness and Win-Win, Adopt Strict Production Technology and Inspection Standards, Select the Best Quality Brand Tractor Parts. To ensure a 100% Quality Standard, We will Independent Development and Production the Core Tractor Parts, Continue to Increase Investment in New Models and Technologies.
The Mission of Tavol Group is to Assemble the Best Tractors With the Best of Heart, and Strive for the Smiles of One billion Farmers; With the Values of Tolerance, Openness and Win-Win, Adopt Strict Production Technology and Inspection Standards, Select the Best Quality Brand Tractor Parts. To ensure a 100% Quality Standard, We will Independent Development and Production the Core Tractor Parts, Continue to Increase Investment in New Models and Technologies.
Q1:Are you the factory or the trading company?
A1:We are the factory,we located in Taian City,Shandong Province,China.
Q2:What after-sales service can your company provide?
A2We can provide technical support and on-site installation support!
Q3:Can you provide spare parts for free?
A3:Of course.
Q4:Can you provide OEM?
A4:Yes,we can.
Q5:How about the delivery time?
A5:15-25 days according to the different quantity.
