Model NO.
LT1204B
Emission Standard
Euro II
Fuel
Gas / Diesel
Service Life
3-6 Years
Size
Small
Color
Red
Condition
New
Wheel Base
2688mm
Max. Traction Force
27kn
Rated Revolution
2300r/Min
Steering
Hydraulic
Rated Power
88kw
Specification
5040*2255*2870mm
Trademark
Top Brand
Origin
China
HS Code
8501109190
Production Capacity
200
After-sales Service:
Online Service
Warranty:
1 Year
Type:
Wheel Tractor
Usage:
Farm Tractor
Certification:
ISO, CE
Drive Wheel:
4WD
Farm Machinery 4WD Agriculture Tractor LT1204BProduct Feature
1.Adopt Xinchai diesel engine, good reliability, large reserves of torque, low fuel consumption, high economic efficiency;
2.Double-function clutch,10 inches, high transmission capacity, reliable, comfortable manipulation;
3.Gearbox using 4 × 3(1 +1) engaging sleeve, shuttle-type gearshift, there are 12 forward gears, 12 reverse gears, reasonable match between the gears, and have high efficiency;
4.Independent power take off device, smooth transmission, large capacity, speed (540/760, 540/1000 r/min) for selection to meet the different operation requirements;
5.Full hydraulic front wheels steering, independent oil circuit for steering system, manipulating flexible, reliable, and save energy;
6.Adopt hydrostatic disc-type brakes, a large braking torque, the braking effect is good;
7.Adopt high pressure type lifting device, reliable, easy maintenance, multi-hydraulic output can be optioned;
8. Final transmission adopts planetary gear mechanism, compact structure, large reduction ratio;
9.New streamlined appearance, generous, modern, fashion;
10.Control levers can be mounted at side as optional, more convenient and comfortable.
Product Parameters
| Tractor Model | LT1004 | LT1104 | LT1204 | LT1304 | |
| General Specification | Driver Type | 4 X 4 | |||
| Length×width×Height(mm) | 5040x2255x2860 | 5040x2255x2870 | 5050x2370x3000 | ||
| Rated Traction force(KN) | 24 | 26 | 27 | 32 | |
| Steering | hydraulic | ||||
| Wheel base(mm) | 2195 | 2688 | |||
| Front wheel tread(mm) | 1610 | 1672--2003 | 1822 --2153 | ||
| Rear wheel tread(mm) | 1620 --2020 | 1662--2262 | |||
| Ground clearance(mm) | 379 | 470 | |||
| Engine | Model | LR4M3Z-23 | LR6B3-23 | LR6M5-23 | |
| Type | Inline,water cooled,four stroke,,direct injection, naturally aspirated | ||||
| Marked power (KW) | 73.5 | 81 | 88.2 | 95.6 | |
| Rated revolution (r/min) | 2300 | ||||
| Transmission | Clutch | 12 inches clutch double action | |||
| Gear box | 16F+8R Gear | 12F+4R Gear | |||
| Working device | Control typeof plough depth | Force,place control and floating control | |||
| Max.lifting capacity( KN ) | 17.7 | ≥20 | ≥24 | ||
| Suspension device type | 3-Point hanging with postposition | ||||
| Speed of P.T.O.(r/min) | Stardard:760/850 8 Spine;optional:540/1000 or 540/760 6 Spine | 540/1000 | |||
| P.T.O.power (KW) | 62.7 | 69.35 | 71.25 | 56.3 | |
| Specific fuel consumption(g/kw.h) | ≤242 | ||||
