Model NO.
LT504
Service Life
≤1 Year
Size
Small
Color
Red
Condition
New
Front Wheel Tread
1265 mm
Rear Wheel Tread
1200 mm
Min. Ground Clearance
330 mm
Rated Power
36.8 Kw
Max. Traction Force
11.7 Kn
Transport Package
Nude
Specification
3770x1620x2130
Trademark
Oriemac
Origin
China
Production Capacity
350units/Month
Type:
Wheel Tractor
Usage:
Farm Tractor, Garden Tractor, Lawn Tractor
Certification:
ISO, CE, EPA, CCC, ISO/TS16949, EEC, XQC
Drive Wheel:
4WD
Emission Standard:
Euro II
Fuel:
Gas / Diesel
Lutong Small Power High Quality 50hp Tractor ME504
Contact Person: Vicky Zhu
Product Description
Product Specifications
Product Show
Company Information
Contact Person: Vicky Zhu
Product Description
Main Features
Adopt Xinchai diesel engine, good reliability, large reserves of torque, low fuel consumption, high economic efficiency;
Double-function clutch,10 inches, high transmission capacity, reliable, comfortable manipulation;
Gearbox using 4 × 3(1 +1) engaging sleeve, shuttle-type gearshift, there are 12 forward gears, 12 reverse gears, reasonable match between the gears, and have high efficiency;
Independent power take off device, smooth transmission, large capacity, speed (540/760, 540/1000 r/min) for selection to meet the different operation requirements;
Full hydraulic front wheels steering, independent oil circuit for steering system, manipulating flexible, reliable, and save energy;
Adopt hydrostatic disc-type brakes, a large braking torque, the braking effect is good;
Adopt high pressure type lifting device, reliable, easy maintenance, multi-hydraulic output can be optioned;
Final transmission adopts planetary gear mechanism, compact structure, large reduction ratio;
New streamlined appearance, generous, modern, fashion;
Control levers can be mounted at side as optional, more convenient and comfortable.
Product Specifications
| Tractor Model | LT504 | |
| Drive Type | ||
| Overall Dimension L×W×H(mm) | 3770×1620×2130 | |
| Wheel base(mm) | 1990 | |
| Front wheel tread(mm) | 1265 | |
| Rear wheel tread(mm) | 1200--1500 (Common 1300) | |
| Min. ground clearance(mm) | 330 | |
| Min. steering radius | Unilateral brake(m) | 3.8 |
| Not unilateral brake(m) | 4.3 | |
| Min. operating weight (KG) | 2080 | |
| Gearbox gears number | 12F+12R | |
| Speed | Forward(Kw/h) | 2.55-34.02 |
| Reverse(Kw/h) | 2.24-29.82 | |
| Engine | Model | A498BT-6A |
| Rated power (Kw) | 36.8 | |
| Rated speed (r/min) | 2400 | |
| Tires spec. | Front tires | 8.3-24 |
| Rear tires | 13.6-28 | |
| Steering Type | Full hydraulic? front wheels steering | |
| Max. lifting force( KN ) | 8.28 | |
| PTO | Type | Rear-mounted, Semi-independent type |
| Speed (r/min) | 540/760 or 540/1000 | |
| Power(Kw)> | ≥31.3 | |
| Control type of ploughing depth | Height control & flotation control | |
| Max. traction force (KN) | 11.7 | |
| Front / rear Ballast (KG) | 104/220 | |
