4 Wheel drive 70-80HP Tractor with Rollbar, Tractor, Wheel Tractor

Supplier Weifang Farm Machinery Co., Ltd.
Price $9100.00 / Piece
Availability In Stock
Mini Order:
+-
Subtotal: $9100

Purchase details

Payments:

Tax:

Tax Included

Returns&Refunds:

Eligible for refunds within 30 days of receiving products. returns and refunds


Model NO.
LZT-804 (704/754)
Emission Standard
National IV
Fuel
Gas / Diesel
Service Life
6-10 Years
Size
Large
Color
Red
Condition
New
Transport Package
by Container
Specification
5230*2380*2980
Trademark
OEM
Origin
Weifang
HS Code
8701
Production Capacity
1000units/Year
After-sales Service:
Online
Warranty:
1 Year After Sale
Type:
Wheel Tractor
Usage:
Farm Tractor, Garden Tractor, Lawn Tractor
Certification:
ISO, CCC
Drive Wheel:
4WD
Choosable Diesel Engine  Wheel Tractor
4 Wheel drive 70-80HP Tractor with Rollbar
4 Wheel drive 70-80HP Tractor with Rollbar



Feature
LZT-804 Tractor: 80hp,4wd,four cylinder,power steering, 12F+12R shuttle shifts,front tyre: 9.5-20 ,rear tyre: 14.9-28,
with rops,blue color hood, blue color ceiling, with multiway valves and three point linkage
Specification
ModelLZT-804
Type4WD
Overall dimensions (mm)3800X1830X2400
Wheel Base (mm)2010
Front Tread (mm)1250
Rear Tread (mm)1300-1500
Min. Ground Clearance325
Min. Operation Mass (kg)2160
Rated PTO Power (kW)43.8
Rated Drawbar pull (kN)12.1
Starting MethodElectric starting
No.of gears12F+12R
Engine Type4-stroke, vertical, 4 cylinders Quanchai 4108 model
Bore X Stroke (mm)108X118
Rated power (kW)58.8
Rated Speed (rpm)2300
Cooling typeWater circulating cooling type
Fuel tank capacity (L)80
Clutchdual stage, dry friction, single plate, constant mesh
Transmission Boxdual axles, composed type
Steering typePower steering
Braking systemdisc type, oil immersed, dual plate
Gearshiftengaging sleeve shifting
Central Drivehelical bevel gear
Differentialclosed planet pinion
Final Drivebevel gear/planet pinion
Front Tyre Size9.5-20
Rear Tyre Size14.9-28
Three Point HitchCategory I, Rear mounted
Hydraulic lift typeSemi-seperated
Tillage depth control methodPosition and draft control
PTO Typetype I, rear mounted, semi-independent, Ø35mmX6teeth
PTO Rev.540/1000rpm
Max. Lifting Force (kN) 12.36
