Model NO.
LZT-704(604/754/804/854)
Emission Standard
National IV
Fuel
Gas / Diesel
Service Life
6-10 Years
Size
Large
Color
Red
Condition
New
Transport Package
by Container
Specification
5230*2380*2980
Trademark
OEM
Origin
Weifang
HS Code
8701
Production Capacity
1000units/Year
After-sales Service:
Online
Warranty:
1 Year After Sale
Type:
Wheel Tractor
Usage:
Farm Tractor, Garden Tractor, Lawn Tractor
Certification:
ISO, CCC
Drive Wheel:
4WD
Choosable Diesel Engine Wheel Tractor
Feature
LZT-704 Tractor: 70hp,4wd,four cylinder,power steering, 12F+12R shuttle shifts,front tyre: 9.5-20 ,rear tyre: 14.9-28,
with sunshade and rollbar,blue color hood, blue color ceiling, with multiway valves and three point linkage
Specification
| Model | LZT-704 |
| Type | 4WD |
| Overall dimensions (mm) | 3800X1830X2400 |
| Wheel Base (mm) | 2010 |
| Front Tread (mm) | 1250 |
| Rear Tread (mm) | 1300-1500 |
| Min. Ground Clearance | 325 |
| Min. Operation Mass (kg) | 2160 |
| Rated PTO Power (kW) | 43.8 |
| Rated Drawbar pull (kN) | 12.1 |
| Starting Method | Electric starting |
| No.of gears | 12F+12R |
| Engine Type | 4-stroke, vertical, 4 cylinders Quanchai 4108 model |
| Bore X Stroke (mm) | 108X118 |
| Rated power (kW) | 51.5 |
| Rated Speed (rpm) | 2300 |
| Cooling type | Water circulating cooling type |
| Fuel tank capacity (L) | 80 |
| Clutch | dual stage, dry friction, single plate, constant mesh |
| Transmission Box | dual axles, composed type |
| Steering type | Power steering |
| Braking system | disc type, oil immersed, dual plate |
| Gearshift | engaging sleeve shifting |
| Central Drive | helical bevel gear |
| Differential | closed planet pinion |
| Final Drive | bevel gear/planet pinion |
| Front Tyre Size | 9.5-20 |
| Rear Tyre Size | 14.9-28 |
| Three Point Hitch | Category I, Rear mounted |
| Hydraulic lift type | Semi-seperated |
| Tillage depth control method | Position and draft control |
| PTO Type | type I, rear mounted, semi-independent, Ø35mmX6teeth |
| PTO Rev. | 540/1000rpm |
| Max. Lifting Force (kN) | 12.36 |
