Model NO.
RC904
Emission Standard
Euro II
Fuel
Gas / Diesel
Service Life
New
Size
Medium
Color
Green
Condition
New
Transport Package
Standard
Specification
4382, 2083, 2810mm
Trademark
CHINA
Origin
China
After-sales Service:
Warranty Available
Warranty:
1 Year
Type:
Wheel Tractor
Usage:
Farm Tractor, Garden Tractor, Lawn Tractor
Certification:
ISO, CE, CCC
Drive Wheel:
4WD
Zoomlion 90HP 4X4 hot sale RC904-A mini Chain Drive agricultural power tiller tractor
RC904-A Wheeled Tractor
A work of painstaking effort, professional for farming
Powerful & reliable
Comfortable driving & easy operation
RC904-A Wheeled Tractor
A work of painstaking effort, professional for farming
Powerful & reliable
* Brand-name and high-quality four-cylinder engine
* The torque reserve coefficient of the independently operated reinforced double-acting clutch is larger and more reliable.
* Gear 16F+8R is equipped for the gearbox, which can be switched to the required working speed of various operations with high efficiency;
* The transmission gear is made of upgraded material and adopts gear grinding technology, which is more reliable;
* The shifting yoke of gearbox is more reliable with longer service life since inblock cast is applied.
Comfortable driving & easy operation
* Side control and meshing sleeve shift are applied for easy operation;
* Full hydraulic steering system enabling convenient and flexibly operation;
* The appearance is designed to be streamlined, which is elegant with wider work view.
Excellent performance and high operation efficiency
Excellent performance and high operation efficiency
* The enhanced two-speed power output can be matched with more machines and tools to meet the needs of various operations.
* The pusher type lifer with double oil cylinder is adopted for more powerful lifting and better operation;
* Two sets of hydraulic output is more adaptable, which can meet the requirements of folding harrow, reversible plow and other operations.
Product parameters:
Product parameters:
| Type | Unit | RC904-A |
| Overall dimension (L× W× H) | mm | 4382×2083×2810 |
| Wheelbase | mm | 2193.5 |
| Minimum mass during operation | kg | 3550 |
| Minimum ground clearance | mm | 415 |
| Engine emission | / | National Emission Standard II |
| Rated power | kw | 66.2 |
| Fuel consumption rate | g/kw•h | ≤225 |
| Cluth type | / | Dry type, independent control double action |
| Number of gears of the gearbox | / | 16F+8R |
| Brake type | / | Wet and disc of single disk |
| Tyre size (front wheel / rear wheel) | / | 12.4-24/16.9-34 |
| Type of hydraulic lifting system | / | Split type |
| Tillage control method | / | Position adjustment and floating control |
| Hydraulic output multiway valve | / | 2 sets of hydraulic output |
| Hydraulic hitch | / | Three-point rear suspension, Class II |
| Traction force | KN | 28.5 |
| Power output speed | r/min | 760/850, optional 760/1000, 540/1000, 540/760 |
| Safety shelf or cab | / | safety shelf and sunshade |
