Model NO.
KPX-25T
Certificate
ISO9000
Capacity
25t
Material
Steel
Type
Power Pallet Truck
Style
Steel Box and Girder
Entry Type
on Railways
Usage
Transfer Steel Coil or Aluminum Coil
Wheel Material
Cast Steel
Control Method
Remote Control
Rail Type
P38
Transport Package
According to The Customer Demand
Specification
GB/T6127-92
Trademark
BEFANBY
Origin
Xinxiang City, Hennan Province, China (Mainland)
HS Code
8428901000
Production Capacity
100 Sets/Month
After-sales Service:
Free Sales Service
Warranty:
2 Years
Fuel:
0
Certification:
ISO9000, CE
Emission Standard:
0
Condition:
New
Product Description
Heavy Duty Pipes Coil Transfer Cart on Rails (KPX-25T)
BEFANBY designed and manufactured the battery powered transfer car and provide innovative handling solution with
more than 20 years'experience.the transfer car can be used in industry plant, port, workshop, production line and so on to
transport ladle,coil, mold, steel products, workpiece and so on.All the solution are designed as per customers true demand.
Heavy Duty Pipes Coil Transfer Cart on Rails (KPX-25T)
BEFANBY designed and manufactured the battery powered transfer car and provide innovative handling solution with
more than 20 years'experience.the transfer car can be used in industry plant, port, workshop, production line and so on to
transport ladle,coil, mold, steel products, workpiece and so on.All the solution are designed as per customers true demand.
The battery powered transfer cart is a good choice if meeting the following features:
1.The running distance is not limited for the battery powered transfer car
2.Low using frequency(The spare battery can be provided if higher using frequency)
3.Despite of turning or going straight, the transfer car can realize
4.Despite of running on indoor or outdoor, high temperarture or explosive environment, ferry or cross rail, the transfer cart
can realize.
5.Dimensions,capacity, loading platform superstructure, speed and many others special funcition can be customized as
per client request.
Details Images
Product Parameter
| Model | KPX-2T | KPX-10T | KPX-20T | KPX-30T | KPX-50T | KPX-63T | |
| Rated load (T) | 2 | 10 | 20 | 30 | 50 | 63 | |
| Table size | length(L) | 2000 | 3600 | 4000 | 4500 | 5500 | 5600 |
| Width(W) | 1500 | 2000 | 2200 | 2200 | 2500 | 2500 | |
| Height(H) | 450 | 500 | 550 | 600 | 650 | 700 | |
| Wheel Base (mm) | 1200 | 2600 | 2800 | 3200 | 4200 | 4300 | |
| Rail Inner Gauge (mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | |
| Wheel Diameter(mm) | Ф270 | Ф300 | Ф350 | Ф400 | Ф500 | Ф600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | |
| Ground Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 75 | |
| Running speed (min) | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | |
| Motor Power (Kw) | 1 | 1.6 | 2.2 | 3.5 | 5 | 6.3 | |
| Battery Capacity(Ah) | 180 | 160 | 180 | 250 | 330 | 400 | |
| Battery Voltage(V) | 24 | 48 | 48 | 48 | 48 | 48 | |
| Running Time When Fu ll Load | 4.32 | 4.8 | 4 | 3.5 | 3.3 | 3 | |
| Max Wheel Load (KN) | 14.4 | 42.6 | 77.7 | 110.4 | 174 | 221.4 | |
| Reference Weight (t) | 2.8 | 4.2 | 5.9 | 6.8 | 8 | 10.8 | |
| Recommended Rail Model | P15 | P18 | P24 | P38 | P43 | P50 | |
Our Advantage
Application
Our Company
Our after-service
1>. Our commitment: The load bearing safety factor of the cart is no less than 120%.
2>.Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material
3>. 16 hours engineering service and 24 hours internet service for our customers
4>. During the warranty period, if our products can't work normally, we can support you repair technology or replace
relevant parts for you within 24 hours.
5>. Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Pres-
erve
How to choose the suitable transfer cart?
All of our coil transfer cart all customized as client's requirement, for choose the most suitable transfer cart,please
kindly providing the following information:
· Transfer or handling what material/cargo?
· What capacity do you need?
· This transfer cart is running on rails or ground(floor)?
· Your requirement for table size:length,width and height?
· How about the running distance?
