Model NO.
UQ-20
Driving Form
4*2
Maxmium Speed
45
Cross Weight
10500kg
Wheel Base
4000
No. of Tires
6
Tires
9.00r20
Grade Ability
20ton
Transport Package
Normal Packing
Specification
10.5t
Trademark
Danlite
Origin
China
HS Code
8704109000
Production Capacity
1000units/Year
After-sales Service:
3-6 Months
Warranty:
3-6 Months
Fuel:
Diesel
Emission Standard:
Euro 4
Condition:
New
Overall Dimensions:
6950*2500*3280
4X2 Mine Truck Wet Brake off-Road Truck Dumper Mining Truck
Combined with the international and domestic underground car modeling, in accordance with the national safety requirements for underground car, the design of this beautiful domenical, spacious and comfortable, convenient maintenance of the dragon skeleton structure, the thickened steel plate, with super anti-collision anti-tumble, has a safer protection role for the driver and passenger.
Combined with the international and domestic underground car modeling, in accordance with the national safety requirements for underground car, the design of this beautiful domenical, spacious and comfortable, convenient maintenance of the dragon skeleton structure, the thickened steel plate, with super anti-collision anti-tumble, has a safer protection role for the driver and passenger.
| Products Technical Specification | ||||
| Product Name | mining truck for underground mine | |||
| Vehicle Dimensions(mm) | ||||
| Overall length | 6950 |  | ||
| width | 2500 | |||
| height (unladen) () | 2380 | |||
| Wheel base | 4000 | |||
| Container volume | 9 m³ | |||
| Maximum loading mass | 20000kg | |||
| Maximum velocity (Km/h) | 45 | |||
| Cross weights (kg) | ||||
| G.V.W | 10500 | |||
| Engine | Type | YC6J245-42 | ||
| Emission level | Euro | |||
| rated power | 180Kw | |||
| rated speed | 2500r/min | |||
| System | Water cooled,turbocharged,after cooled,direct injection,High pressure common rail fuel system,heating for starting. | |||
| Gear box | Type | Fast 7DS118 | ||
| No. of gears | 7forward gears & 1reverse | |||
| Gear ratios | 10.222,5.426,3.538,2.527,1.82,1.327,1,R1-9.043 | |||
| Brake System | Hydraulic wet brake, hydraulic spring brake, break pressing, pressure supply driving | |||
| Axle | Front | Elliot type, I beam section | ||
| Load capacity(ton) | 7 | |||
| Rear | Double reduction ,tandem axle, with axle lock and wheel lock | |||
| Load capacity(ton) | 16 | |||
| Tyres | 9.00R20 | |||
| Cab | Full rigid frame straight cab, all welded steel cab of tilt type,antirust covering.Mechanical driver's seat, wind shield wiper and washer, rear mechanical cab suspension,air conditioning system | |||
| Body | Refit configuration:6950mmx2500mmx2380mm, High strength wear resistant steel plate, rectangular box,side 8mm,bottom 12mm. | |||
