Model NO.
CLW
Payload
10t
Fuel
Diesel
Drive Wheel
4×2
Brand
Dongfeng Foton Forland HOWO
Models
Medium
Usage
Compression Type
Condition
New
After-Sales Service Provided
Overseas Third-Party Support
Truck Type
Sanitation Vehicle
Wheelbase
4500mm
Name
Compactor Garbage Truck
Color
Request Customized
Key Word
Garbage Truck, Garbage Compactor Truck
Transport Package
Nude Packing with Surface Wax or According to The
Specification
8500*2500*3110
Trademark
CLW
Origin
Hubei, China (Mainland)
HS Code
8704223000
Production Capacity
5000 Unit/Units Per Month
Warranty:
12 Months
Type:
Compactor
Certification:
ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
Volume:
10001-15000L
Emission Standard:
Euro 3
Transmission Type:
Manual
12cbm Rear Loaded Compactor Garbage Truck
Garbage compactor (also called waste compactor truck, garbage compactor truck, trash compactor, refuse collection truck, compactor garbage truck,rubbish truck, bin wagon, dustcart, bin lorry, waste collection vehicle) is designed to collect and transport municipal solid waste.
Garbage compactor is composed of hermitical garbage box, hydraulic system and operating system, which could apply pressure to the waste to break down bulky items, to load and transport more garbage by one time. Dirty liquid flows into waste sink, perfectly preventing repollution. When arriving at destination, the garbage can be dumped completely. It is ideal solution for solid waste collection.
Product Parameters
Product Images
Product Details
About us
Truck Exported
Customer Visiting
Contact us
Contact us
Export Director : Jenny Cheng
CHENGLI SPECIAL AUTOMOBILE CO., LTD
Factory Add: South Suburb, Chengli Automobile Industry Park, Suizhou City, Hubei Province, China
Garbage compactor (also called waste compactor truck, garbage compactor truck, trash compactor, refuse collection truck, compactor garbage truck,rubbish truck, bin wagon, dustcart, bin lorry, waste collection vehicle) is designed to collect and transport municipal solid waste.
Garbage compactor is composed of hermitical garbage box, hydraulic system and operating system, which could apply pressure to the waste to break down bulky items, to load and transport more garbage by one time. Dirty liquid flows into waste sink, perfectly preventing repollution. When arriving at destination, the garbage can be dumped completely. It is ideal solution for solid waste collection.
Product Parameters
| Chassis Description | |
| Cab | Single row non-longhead cab can turn over |
| Color | Optional |
| Allowable person in cab | 2/3 |
| Wheel base (mm) | 4500 |
| Number of axles | 2 |
| Front axle | 5000 |
| Rear axle | 10000 |
| Traction system | 4×2 |
| Tire quantity | 6+1 |
| Engine Description | |
| Emission standard | Euro 3 |
| Exhaust/output | 5900ml/140kw |
| Horse power | 190hp |
| Up-parts Description | |
| Loading Circulation Time (s) | 12-30 |
| Rubbish Discharging Time(s) | <30 |
| Oil Pressure(Mpa/kg) | 19.6/200 |
| Factual loading(kg) | 10000 |
| Compressed Proportion | 1:3/1:2 |
| Power of movement | Hydraulic pump |
| Standard Equipment | Equipped with hermetic dustbin, hydraulic system and operating system Automatic compress and uninstall, sewage can be collected by the dump tank. Pressure is large, leakproofness is good, operation is convenient and security is dependable |
