Model NO.
CLWGC5088ZYSB6
Fuel
Diesel
Drive Wheel
4×2
Brand
FOTON
Models
Small
Usage
Compression Type
Condition
New
Product Name
Garbage Compactor Truck
Garbage Collection
Household Waste, Domestic Garbage, Non-Medical
Other Name
Refuse Collection Vehicle (Rcv), Refuse Compactor
Garbage Tank Volume
6000 L
Compression Pressure
16 MPa
Garbage Tank Material
Q345 (Manganese Steel)
Compression Mechanism
Bi-Directional Compression
Garbage Tank Thickness
4/4 mm (Wall/Floor)
Compression Ratio
1:0.8
Garbage Loading Mechanism
Rear-Loader (240 L Garbage Bin)
Controlling Methodology
Manual and Electrical
Garbage Loading Capacity
5000 Kg
Transport Package
Wax-Polishing Before Shipping
Specification
6790*2150*2650 mm
Trademark
CLVEHICLES
Origin
Hubei, Mainland, China
HS Code
8704210000
Type:
Compactor
Certification:
ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
Volume:
3001-6000L
Emission Standard:
Euro 3
Transmission Type:
Manual
Payload:
5t
| FOTON 4x2 153hp 6m3 Compactor garbage truck | |||
| Vehicle | Bodywork | ||
| Speed | 105 km/h | Garbage tank form | Arc-shaped |
| Passenger | 2 | Garbage tank volume | 6000 L |
| Wheelbase | 3300 mm | Garbage tank material | Manganese Steel (Q345) |
| Tyre | 7.50R16LT 14PR | Garbage tank thickness | 4/4 mm (floor/wall plate) |
| Engine power | 156 hp (115 kw) | Garbage compression ratio | 1:0.8 |
| Displacement | 27800 ml | Garbage compression pressure | 16 mpa |
| Principle | |||
Garbage compactor truck (also known as Refuse Compactor, Refuse Collection Vehicle/RCV) is a special type of urban environmental sanitation vehicle that collects and transports garbage, which can prevent secondary pollution caused by spilling along the road. Waste collected inside the compactor is pushed out of the container through a hydraulically powered Ejection Plate. Two men (driver and operator) are required to perform the entire functionality of the compactor.  | |||
| Application | |||
 | |||
| Advantages | |||
1. Simple, efficient garbage collection; 2. Automatic repeated compacting function with high compression ratio; 3. More garbage loading capacity; 4. Automatic operation;(labor saving) 5. Environmental-friendly; 6. High efficiency of vehicle utilization; 7. Decent sealing characteristics; | |||
| Reference | |||
    One-key Control Panel (inside the cabin)  PLC Electrical Control Panel at Tail of Left/Right Ends  Manual Handle Control For Hydraulic Cylinder Compacting Process  | |||
   | |||
