Right Hand Drive Howo Hydraulic Compaction Garbage Trucks 6CBM Capacity,Howo Refuse Compactor Special Vehicle
Mini Howo Refuse Compactor Vehicle Capacity 4-8T
Sino Truck Howo Garbage Truck Compactor Garbage Truck,trash Truck
Capacity 4CBM-8CBM,as you wish.
China Sinotruck HOWO 8cbm Diesel Refuse Waste Compactor
Compressed Garbage Truck Price
Garbage Compactor Truck is the machinery of choice for door to door collection of waste.
The collected waste is simultaneously compacted and eventually transported to the dumping site.
Compactors have multiple benefits over conventional waste trolleys namely:
Waste is covered and there is no chance of "spillage" of waste during transportation.
Continuous compaction allows more waste to be stuffed onto a truck which reduces the number of round trips to the dumping site. This results in significant fuel saving.Waste collected inside the compactor is pushed out of the container through a hydraulically powered Ejection Plate.
Two men are required to perform the entire functionality of the compactor namely, driver and operator.
Hubei DRZ manufactures compactors with various capacities depending on the type of truck chassis and user requirement.
Chassic:Sino Trucks,Japan I.SUZU trucks,Beiben trucks , Shacman trucks ,
FAW trucks ,Hongyan trucks,FOTON trucks , Dongfeng trucks , JAC trucks
HOWO mini 5m3 Compactor Garbage Truck 4 Tons Garbage Truck,
HOWO mini 5M3 Compressed Garbage Truck 4tons Garbage compactor
Truck for sale
Pictures for Sino Truck Howo Garbage Truck Compactor Garbage Truck,
Howo trash Truck Capacity 4CBM-8CBM
cabin | Driving type 4x2 | ||
2080 Standard cab, with threeseats,with A/C. Left Hand Driven. 70°hydraulically tillable to the front as attached photo for ref. | |||
Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 8000x2450x3100 | |
Wheel base (mm) | 4500 | ||
Wheel track (front/rear) (mm) | 1798/1764 | ||
Approach/Departure angle(°) | 27/20 | ||
Weight in KGS | Tare Weight | 6400 | |
Loading Capacity | 5000 | ||
Front axles loading capacity | 1x3200 | ||
Rear axles loading capacity | 1x8200 | ||
Max. driving speed(km/h) | 90 | ||
Engine | Brand | YUCHAI | |
Model | YC4E140-20 | ||
Type | 4-stroke direct injection , 4-cylinder in-line with water cooling, | ||
Horse Power(HP) | 140 HP-160 HP | ||
Emission standard | Euro | ||
Gearbox | WLY6T51 , 6 forwards &1 reverse | ||
Clutch | Diaphragm spring clutch | ||
Steering Gear | Power steering | ||
Fuel tank (L) | 230 L | ||
Tire | 8.25R20 All radial tires with one spare, 7 pieces | ||
Compression garbage box body system | |||
BodyVolume | 8 CBM | ||
Cycle Time of Filling(S) | ≤40 | ||
Lifting Time of Filler(S) | 8-10 | ||
Time of Discharging | ≤60 | ||
Working Pressure(MPA) | 16 | ||
Composed by hermetic garbage tank, hydraulic system, operation system. The entire truck is hermetic, can automatically compress and dump the garbage .and the sewage generated in the process of the compression all go into the sewage tank. | |||
The pictures of HOWO mini 5M3 Compressed Garbage Truck 4tons Garbage compactor Truck,
| Dispensing System | 1. Equipped with air-tight dustbin, hydraulic system and operating system. 2. Automatic loading, compressing and discharging, all handled by 1 person. 3. Sewage water collection tank to avoid any pollution during handling. 4. Large Pressure, Good Leakage Proof, Convenient Operation Dependable Security. 5. Electrical Control Panel for compacting system. | |
- Optional equipments are included in these photographs
- Specifications and dimensions are subject to change without notice.
- Material : Anti-corrosion Steel
- Material : Anti-corrosion Steel or High-tensile Steel
- Material : High-tensile Steel
Sinotruk HOWO 6-wheel 5M3 garbage compactor truck 4 tons compactor garbage trucks for sale:
More information for Sino Truck Howo Garbage Truck Compactor Garbage Truck,
trash Truck Capacity 4CBM-8CBM please contact with me
