Model NO.
ND5256GJBZ
Drive Mode
6x4
Maximum Horsepower
300-400hp
Condition
New
Gvw
25000kg
Drum Mixing Volume
5cbm
Reducer
Imported Brand
Radiator
Chinese Top Brand
Cab
Beiben
Tire Specification
12.00r20
Tire Quantity
10+1 Units
Engine Model
Wp10 . 340e32
Gear Box
Fast 9t - 1680
Steering Mechanism
Tas85
Wheelbase
4100 + 1450mm
Transport Package
After Waxing by Container, RO-RO, Bulk Freighter
Specification
9400*2500*3900mm
Trademark
SUNY
Origin
China
HS Code
081995491
Production Capacity
1000 Units/Year
Certification:
ISO9000, CCC, CE
Transmission Type:
Manual
Emission Standard:
Euro 3
Displacement:
9.7
Payload:
20T
Fuel:
Diesel
6X4 Benz 5 M3 Concrete Mixer Tank Truck for sale
Product Description:
Concrete mixer truck is used for transporting mixing concrete to the construction site, mixing station.The mixer drum maintains the agitation and turning until delivery during the transportation.The main components include hydraulic system, reducer and radiator, which brand could be imported or Chinese.The cubage could be 2cbm to 16cbm.
FAQ
1. What is your terms of payment?
T/T with 30% deposit, and 70% balance will be paid before delivery.
We will show you photos of the products and packages before you paying the balance.
2. What's your minimum quantity?
1 set.
3. What is your packing?
Naked packing, we transport our trailers by bulk cargo carrier, ro-ro or 40/45 HQ or land transportation.
4. How about delivery time?
Generally speaking, 25 workdays after we received 30% of contract value T/T down payment. The specific delivery time depends on the products and the quantity of your order.
5.How to judge the quality of products?
We will show you photos and videos, trading order. You are welcome to visit our factory at any time.
6.Why you trust and choose us?
--Complete production line, from trailer Design to Delivery.
-- ISO 9001: 2008 and CCC quality certificate.
--Use 100% famous brand spare parts you want.
-- Accept customization requirements.
--We are trusted by the clients from Africa, Australia, South America, Indonesia and so on.
--We accept flexible payment terms,T/T, L/C, or other .
7. Can I customize the painting and the logo?
Yes, we offer customized logo for any type.
Please contact us for more details
Website:http://findtextile.com/store/sanyan
24hours online,waiting for your kind inquire.
Welcome to our factory,We will pick up you from the airport.
Product Description:
Concrete mixer truck is used for transporting mixing concrete to the construction site, mixing station.The mixer drum maintains the agitation and turning until delivery during the transportation.The main components include hydraulic system, reducer and radiator, which brand could be imported or Chinese.The cubage could be 2cbm to 16cbm.
| Beiben 5m3 concrete mixer truck ND5256GJBZ | ||
Whole Vehicle Parameters | Chassis | BEIBEN |
| Curb weight ( kg ) | 12780 | |
| Total vehicle weight ( kg ) | 25000 | |
| Overall dimensions ( L * W * H ) | 9400 x 2500 x 3900 | |
| Wheelbase ( mm ) | 4100 + 1450 | |
| Front overhang ( mm ) | 1410 | |
| Rear overhang ( mm ) | 2640 | |
| Max. Traveling speed ( km / h ) | 85 | |
Vehicle Configuration | Clutch | Dry single dis clutch ( Φ 430 ) |
| Gearbox | FAST 9T - 1680 | |
| Driving type | 6 x 4 | |
| Steering mechanism | TAS85 | |
| Service brake | Dual - circuit air brake | |
| Parking braking | Spring - powered Air - cut - off brake | |
| Auxiliary brake | Engine exhaust brake | |
| Tire | 12 . 00R20 radial tire | |
Engine Parameters | Model | WP10 . 340E32 |
| Feature | Diesel , 4 stroke , Direct injection , 6 cylinder in line , Turbo - charging , Inner cooling | |
| Emission standard | Euro 3 | |
| Max power ( kw ) | 340hp | |
| Max torque ( N . m ) | 1500 | |
Mixing Drum Parameters | Max mixing cubage ( m ³ ) | 5 |
| Feeding speed ( m ³ ) | 3 . 5 | |
| Discharging speed ( m ³ ) | 3 | |
| Leftover rate | Nearly Zero | |
| Max Rotating Speed ( R / min ) | 14 - 16 | |
| Mixing Drum Obliquity ( ° ) | 10 | |
| Max mixing drum diameter ( mm ) | Φ 2412 | |
Driving System | Hydraulic Pump | Italian TOP089 |
| Hydraulic Motor | TOP 089 | |
| Speed reducer | TOP P68 | |
| Water supply mode | Water pump ; pneumatic pump | |
FAQ
1. What is your terms of payment?
T/T with 30% deposit, and 70% balance will be paid before delivery.
We will show you photos of the products and packages before you paying the balance.
2. What's your minimum quantity?
1 set.
3. What is your packing?
Naked packing, we transport our trailers by bulk cargo carrier, ro-ro or 40/45 HQ or land transportation.
4. How about delivery time?
Generally speaking, 25 workdays after we received 30% of contract value T/T down payment. The specific delivery time depends on the products and the quantity of your order.
5.How to judge the quality of products?
We will show you photos and videos, trading order. You are welcome to visit our factory at any time.
6.Why you trust and choose us?
--Complete production line, from trailer Design to Delivery.
-- ISO 9001: 2008 and CCC quality certificate.
--Use 100% famous brand spare parts you want.
-- Accept customization requirements.
--We are trusted by the clients from Africa, Australia, South America, Indonesia and so on.
--We accept flexible payment terms,T/T, L/C, or other .
7. Can I customize the painting and the logo?
Yes, we offer customized logo for any type.
Please contact us for more details
Website:http://findtextile.com/store/sanyan
24hours online,waiting for your kind inquire.
Welcome to our factory,We will pick up you from the airport.
