Product Description
Geometric volume: 23.7m³
Agitation volume: 15m³
Maximum diameter of the tank: 2432mm
Technical Parameters
Model |
| HDT5256GJB |
Overall Length | mm | 9880 |
Overall Width | Mm | 2496 |
Overall Height | Mm | 3920 |
Chassis Model |
| Shacman |
Total Vehicle Weight | Kg | 25000 |
Curb Weight | Kg | 15000 |
Wheelbase | mm | 4025+1350 |
Front Tread | mm | 2022/2041 |
Rear Tread | mm | 1830 |
Tyre Type |
| 11.00-20/12.00-20 |
Front Overhang | mm | 1500 |
Rear Overhang | mm | 2980 |
Minimum Turning Diameter | M | ≤20 |
Max Traveling Speed | Km/h | 86 |
Steering Mechanism |
| ZF8098 |
Oil Consumption per 100 km (under limited conditions) | L | 36 |
Engine Model |
| P11C-UH,WD615.95 |
Engine Type |
| Water-cooled, Supercharged, Inter-cooled, Electric (Direct) Injection Diesel Engine |
Cylinder Arrangement |
| 6 Cylinders in Line |
Engine Power /Rotating Speed | HP/(r/min) | 336/2200 |
Max Engine Torque | N.M | 1420/1100, 1400/ (1300-1600) |
Geometric Volume of Mixing Drum | M3 | 16.8 |
Mixing Cubage | M3 | 10 |
Mixing Drum Obliquity | ° | 12 |
Drum Rotating Speed | r/min | 0-14 |
Feeding Speed | M3/min | ≥3.5 |
Discharging Speed | M3/min | ≥3 |
Slump | mm | 100-230 |
Leftover Rate | % | Nearly Zero |
Water Tank Capacity | L | 260/400 |
Water Supply Mode |
| Pneumatic Pump |
