Product description
Self-loading concrete mixer is the combination of concrete mixer truck and cement mixer, which can automatically feed, measure, mix and discharge concrete mixture. Equipped with a powerful engine and 4 wheel steering, the self loading concrete mixer is just like a small car and the operator can drive it to where it needs to go. It is very convenient for loading material, such as cement, aggregate, stone. The raw material is scattered in the construction site. With self loading mixer machine, you will never to worry about transporting raw material.
The efficient self loading mixer concrete machine just need one operator to drive, load, and mix raw material while moving it. It has a higher working efficiency, higher mixing effect. At the same time, it greatly reduces the labor cost and working time. The self loading concrete mixers can bring you great benefits. Compared with concrete mobile mixer, the self loader mobile cement mixer truck.
2. The self loading mixer for sale has easy operation, high working efficiency, high mixing effect.
3. It has independent water supply system, which can ensure the high quality of concrete.
4. It just need one operator to drive, load, and mix raw material while moving it.
Parameter
Name | Item | Specification | |||
Overall dimension | Net weight | 9000kg | |||
Transmission | Full Hydraulic | ||||
4 WD | |||||
Brake | Air Brake | ||||
Chassis | Off-road | ||||
Tread | 1880 | ||||
Wheelbase | 2350mm | ||||
Loader bucket | capacity | 0.6m3 | |||
Control | Hydraulic | ||||
Tilt angle | 30% |
| |||
Speed | High | 20-40KM/H | |||
Low | 0-20KM/H | ||||
Mini turning radius | 6.5M/R | ||||
Tyre model | 16/70-20 | ||||
Engine | Type | YUCHAI |
| ||
Rated Power/RPM | 95KW/2200RPM
| ||||
Max. Torque/RPM | 460N.M/1400RPM | ||||
Cylinder | 4 | ||||
Starter | Electric | ||||
Cooling type | water cooling | ||||
Maxing drum | Output capacity | 4M3 | |||
Bank Angle | 16 ° | ||||
Rotation Angle | 19-21R/min
| ||||
Chute | Swing Angle | ≥60° | |||
Angle control | Hydraulic | ||||
Size | Long 176cm | ||||
Short 40cm | |||||
Loader | Weighing model | computer control | |||
Concrete Standard | C15.C20.C25 C30 | ||||
Accuracy | Cement | ≤±2%/time | |||
Relative Error | ≤±3%/time | ||||
water | ≤±1%/time | ||||
Additive | ≤±1%/time | ||||
Admixture | ≤±2%/time | ||||
Loader control | Hydraulic 4 way stick | ||||
Hydraulic oil tank | 240L | ||||
Water tank | 500L | ||||
Over size | 7500*2700*3380mm | ||||
