Model NO.
CLW5089AWG
Bearing Capacity
Small
Car Type
Van
Condition
New
Material
Fiberglass, Polyurethane Foam, Stainless Steel
Insulating Layer
80mm Polyurethane Foam
Truck Refrigeration Unit
Thermoking, Carrier or Chinese Alternative
Logo
as Per Customer′s Request
Chassis Brand
Dongfeng, Foton, Sinotruk HOWO, Isuzu, Jmc, etc.
Box Material
Fiberglass
Delivery Time
20 Days
Gearbox
Fast, 5 Forward & 1 Reverse
Thickness
80-100mm
Wheelbase
3360mm
Refrigerator
Thermo King/Carrier/Dongin Thermo/Chinese Brand
Transmission
Manual
Applicable Temperature
-18~0 Degree
Warranty
1 Year
Refrigerator Box Size
4150*1750*1750(mm)
Transport Package
Naked, Waxed, Bulk Ship, RO-RO
Specification
5995X1950X2900(mm)
Trademark
CLW
Origin
Suizhou, China
HS Code
8705909090
Production Capacity
500 Unit/Month
Certification:
ISO9000, CCC, CE
Payload:
5tons
Emission Standard:
Euro 3
Transmission Type:
Manual
Horsepower:
＜150hp
Fuel:
Diesel
JMC 4X2 5tons Small Refrigerator Box Truck Light Freezer Refrigerated Truck Factory Direct Sales
1. LPG Tank Truck Trailer/ Fuel Tanker Truck/ LPG station
2. Water truck / Water Tank Truck / Water Sprinkler Truck/Water Tanker
3. Truck with crane / Truck mounted crane
4. Dump Truck / Tipper Truck/Side Tipper/End Tipper
5. Fire Fighting Truck / Fire Truck / Fire Vehicle
6. Concrete Mixer Truck
7. Van truck /Refrigerated truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truc
12. Tractor
13. High Pressure Cleaning Truck
14. Sweeper Truck
15. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
Product Description
1. Purpose of the truck : transport frozen fish, meat, fresh vegetables and vaccinum, etc.
2. Main parts of the truck: Refrigerating unit and control system.
3. Features of the truck: International chassis brands and refrigerating unit brands for optional.
Product Specification
| General Technical Parameters | ||||
| Overall Dimension | 5995×1950×2900(mm) | Gross Vehicle Weight | 4495 (Kg) | |
| Curb Weight | 2805 (Kg) | Loading Weight | 1495(Kg) | |
| Chassis Specification | ||||
| Chassis parameters | Chassis Brand | JMC | ||
| Cabin | Single, Left Hand Driving, with A/C | |||
| Engine | Model | 4 Cylinders | ||
| Power | 85 KW/115 HP | |||
| Emission standard | EURO II | |||
| Displacement | 2780 ml | |||
| Fuel type | Diesel | |||
| Gearbox | 5 Forward & 1 Reverse Gear | |||
| Front and Rear Axle load | 2.5T/4.8T | |||
| Wheel base | 3360(mm) | |||
| Brake System | Oil brake | |||
| Steering Gear | Power Assistant | |||
| Tire | 7.00-16, 6 Pieces with 1 Spare Tire | |||
| Maximum speed | 90 (km/h) | |||
| Superstructure | ||||
| Van | Box size | 4150×1750×1750(mm) | ||
| Material | Fiberglass | |||
| Insulating Layer | 8cm Polyurethane Foam | |||
| Refrigerator | Brand | Thermoking | ||
| Applicable temperature (ºC) | -18~0 | |||
| Remarks | Part Optional: Ventilation slot Hook External power supply Side door | |||
