1. Purpose: It is used for transporting frozen fish, meat, chicken, duck, fresh vegetable and vaccinum etc.
2. Main parts: Refrigerating unit and control system.
3. Features: International chassis brand and International refrigerating unit brand for optional.
Specification:
Car volume: 6 cubic meters,
Size: 2680×1500×1550.
Car body material: FRP is used both inside and outside.
Filled with 8cm polyurethane insulation in the middle, and patterned aluminum bottom plate.
Refrigeration temperature: -15°-0°.
Loading and unloading function: rear double doors.
Feature:
The lowest temperature can reach -25ºC;
The box is made of cold outer glass fiber reinforced plastic, which is beautiful, dirt-resistant and easy to clean.
Filled with polyurethane foam insulation in the middle, with good sealing performance,
Strictly control the temperature of the box to ensure low temperature without freezing, so as not to freeze the goods
Name | Dongfeng mini refrigerated truck |
Overall dimension | 4275x1620x1870mm |
Van dimension | 2680x1500x1550mm |
| BOX Volume | 6cbm |
Curb weight | 1480kg |
Max payload | 540kg |
Drive type | Left hand drive |
Drive wheel | 4X2 |
Tire | 175/70R14LT 4pcs |
Front/rear tread | 1360mm/1360mm |
Front/rear suspension | 560/1250mm |
Wheelbase | 2900mm |
Leaf spring number | -/6 |
Emission | Euro 5 |
Displacement | 1243ml |
Horse power | 98hp |
Braking system | With ABS system |
Max speed | 90km/h |
Fuel type | gasoline |
Painting | With shot blasting and 4 layers painting,color is optional. |
1.Reference photos
2.The rear double doors improve the efficiency of loading and unloading
3.Usage and advantage:
4.Optional structures:
ChengLi Special Automobile Corporation Limited, The CLW group, which was appointed by the Development and Reform Committee of China. ChengLi is a professional company who deal in different kinds of special vehicles, trailers and construction machinery.
- Certificate: ASM, ISO, BV, SGS, CCC etc.
- 12 independents workshops.
- 1000 sets of equipment, 25 assemble lines.
- 300 senior engineers and technicians. About 8000 workers.
- 800kinds of LPG, trucks and semi-trailers.
- 20 years wholesale experience
- Turnover 250 million and Export 20million annually
- Turnover 2 billion trucks and semi-trailers annually.
- LPG/Truck Sold to 90 countries
- Cooperates DONGFENG,SINOTRUCK,FOTON,FAW,BEIBEN,ETC
Overseas Exhibition and Local Support
Customer Visiting and inspection
Warranty
1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.
