Fuel
Diesel
Tank Volume
16000liters 16000L
Drive Wheel
6x4
Hoesrpower
371HP
Condition
New
Fuel Type
Diesel
Drive Model
LHD or Rhd HOWO Sewage Truck
Gearbox
10 Forwards & 2 Reverse HOWO Sewage Truck
Tank Material
6mm Carbon Steel HOWO Sewage Truck
Vacuum Pump
Chinese Brand or Bp, Jurop, Moro Brand
Sewage Suction Pipe
7m
Suction Time
<5min
Effective Suction Range
>8m
Painting
Customized
Delivery Time
30 Days
Certificate
ISO CCC SGS BV
Tanker Volume
16m3, 16cbm, 16000L, 16000liters
Chassis Brand
HOWO, Dongfeng, Isu-Zu, Foton, JAC, etc.
Tire
10 Tires with One Spare
Usage
Sewage Cleaning
Transport Package
Naked, RO-RO, Bulk
Specification
9590*2500*3800mm
Trademark
CLW
Origin
Suizhou, China
HS Code
87059099
Production Capacity
500 Units/Month
After-sales Service:
Life Long Service
Warranty:
1 Year for Major Parts
Certification:
ISO9000, CCC, TS16949, CE
Emission Standard:
Euro 2
Payload:
16tons, 16mt, 16tones
Transmission Type:
Manual
HOWO 16CBM Sewage Vacuum Truck Sewer Cleaning Truck with Jurpo Vacuum Pump
1. Chassis: SINOTRUCK HOWO 371HP
1) Drive type: 6x4
2) Our factory has good business relationship with DONGFENG, FOTON, ISU-ZU, FAW, SINOTRUCK, SHACMAN, JAC, JMC, etc.
2. Tanker body:From 2m3 to 25 m3 capacity for option
3. Accessory of sewage suction factions: Equipped with PTO, transmission shaft, vacuum suction sewage pump, high pressure molding tank, moisture separator, gas-oil separation, multiple directional control valve, hanger rod, self-discharging valve, suck fecal gun and pipe network system.
| Complete Vehicle Parameter | |
| Vehicle | HOWO sewage suction truck |
| Overall dimension (mm) | 9590×2500×3800 |
| Sewage tank (m3) | 16m3/16cbm septic tanker truck |
| Gross vehicle weight (kg) | Appro×25000 |
| Curb weight (kg) | Appro×13000 |
| Payload (kg) | Appro×12000 |
| Wheel base (mm) | 4350+1300 |
| Max speed (km/h) | 90 |
| Chassis Parameter | |
| Cabin | Flat top cabin,a sleeper,power steering, air conditioner, 3 passengers,left hand drive,with Air Conditioner |
| Drive form | 6X4 |
| Engine | Brand: SINOTRUCK |
| Model: WD615.47,371HP | |
| Type: diesel, turbocharged, 6 cylinder. | |
| Displacement: 9726ml | |
| Emission standard: Euro 2 | |
| Transmission | 10 forward,2 reverse, manual operated |
| Tire model | 12R22.5 |
| No.of tires | 10 pcs, with 1pc spare tire |
| Superstructure Parameter | |
| Characteristic | 1. Sewage tank volume 16000 liter/16cbm Septic tanker truck |
| 2. Sewage tank material is carbon steel,thickness 5mm. | |
| 3. Sewage suction pipe 1pcs, length 7m. | |
| 4. Hydraulic lifting sewage tank,rear cover can open. | |
| 5. Equipped with PTO. | |
| 6. Equipped with vacuum pump. | |
| 7. Equipped with oil water separator, overflow valve,looking sewage window, self flow exit,hand washing device. | |
| Performance | (1) Vertical suction ≥ 7m. |
| (2) Pumping speed : 45L/s. | |
| (3) Intake and exhaust diameter: 50mm. | |
| (4) Full tank pumping time ≤ 5min. | |
| (5) Sewage tank emptying time ≤ 4min. | |
