Model NO.
BDP
Certification
CE, ISO, CCC
Lift Mode
Hydraulic Cylinder
Voltage
Customize
Transport Package
Standard Export Package
Specification
customize
Trademark
mutrade
Origin
China
HS Code
842890
Production Capacity
5000
Type:
Hydraulic Parking System
Working Mode:
Button
Driving:
Hydraulic
Falling Prevention Device:
Shaft
The Vehicle Inlet and Outlet:
Center
Design:
Puzzle
| Model | BDP -2 | Voltage | 110-440v, 1or3phase |
| Lifting capacity | 2000kg/2500kg | Operation | key switch |
| Lifting height | 2100mm/82inch | Certification | TUV |
| Power | 2200w | Warranty | 1 years |
| Platform width | 2100mm/82inch | Safety feature | dynamic lock |
| middle posts | sharing post feature | MOQ | 1 set |
| Driving mode | Hydraulic | Finishing | Powder coating |
| Lifting speed | about 35s | Port | Qingdao |
Detailed Images
Product Advantages1.Top quality processing
The BDP SERIES products are 100% cut by Laser and more than 60% welded by robot.
2.Dynamic locking device
We are offering the safest parking machine in the market, the equipment is built under the TUV CE standard and there are more than 10 safety features to ensure our clients will always get protection. Especially, there are a range of locking tabs on the posts to protect cars from accident damage.
3.Fast and easy installation
With professional design and friendly package, it becomes simple on installation. What's more, detailed installation manual, drawing and video attached with products will help customers have easier installation work.
4.Sharing post feature
The posts could be shared when they are installed side by side, which can save cost, land space, and container space.
5.Professional packing & delivery
We have very professional packaging and logistic people to ensure our customer will get the product damage free , simple load & unload in time.
6.Hydraulic driving mode
Thanks to the hydraulic driving mode, our lift could have a faster lifting speed. Even though there is power failure, the upper car still can be retrieved by manually operating the solenoid valve.
7.Low usage cost
When the platform moves down, it will be driven by gravity, so there is no electricity consumption for hydraulic power pack .
8.Stronger structure
Accurate inset structure is adopted to make steel plates jointed stronger so we can park cars forwarder or backwarder.
