Vehicle parameters

Vehicle Model

DRZ5163GSSB

Vehicle Brand

Dong Runze

Overall dimensions

9000X2490X3150mm

Curb weight

6500kg

Tank dimensions

5100X2150X1400mm

Tank volume

12000L

Chassis parameters

Chassis model

BJ1163VKPGG-1

Chassis brand

FOTON

Overall dimensions

8805x2364x2760mm

Wheel base

5000mm

Front/rear wheel track

1900/1800mm

Front/rear suspension

1365/2440mm

Approach/departure angle

20/10°

Maximum speed

90km/h

Chassis Manufacturer

Beijing Foton Daimler Motor Co., Ltd.

Cab

Configuration

A row and a half cab(with sleeping berth),allowable 3 passengers, ETX2200 flat top,air conditioner

Color

Red,other color is optional

Engine

Model

Phaser160Ti-33

Emission

Euro 3

Type

6 cylinders,in-line,4-stroke,water-cooled,turbo inter-cooling, direct injection, dry cylinder liner,diesel engine,

Rated power

160hp,rated power speed 2500rpm

Displacement

5990ml

Max.torque

560N.m

Bore x stroke

100x127mm

Manufacturer

Tianjin Lovol Engine Co., Ltd

Tire

Size

9.00R20 steel wire tire

Number

6+1 nos

Fuel tank

200L aluminum alloy

Rear axle

8.0 tons

Drive form

4X2

Rated voltage

24V,DC

Transmissions

Datong 6 speed forward 1 reverse

Steering device

Power assisted steering

Steering wheel

Left hand drive

Selective configuration

Engine 190hp,8 speed forward 1 reverse, rear axle 9.0 tons

If there is a slight change in the chassis parameters above,please take the actual product as the standard

Water tank structure parameters

Tank dimensions

5100X2150X1400mm

Tank volume

12000L

Tank material

Carbon steel

Tank thickness

4/5mm

Nozzle sprinkling width

≥14m

Range of water cannon

≥28m

Suction height

≥7m

Color and Logo

Optional

Standard configuration

Chassis, sub frame, carbon steel water tank, manhole, water pump, front/side/rear spray nozzle,rear working platform,water cannon,fire valve, water valve, filter gauze,water hose, climbing ladder.

Selective configuration

Stainless steel/aluminum alloy water tank,insulation layer for water tank,stainless steel water pump, fire pump, fire gun,pesticide plate, cabin gas control operated, Honda pumps, lights, crane, hanging basket, rear spraying device, barrel pesticide spraying device, gasoline pesticide machine, diesel pesticide machine, LED arrow lights

Extended model

water transporting truck, thermal insulation water transporting truck, drinking water tank truck, liquid food truck, fire water tank truck, pesticide spraying truck,and etc.
