» II. WRECK TOW TRUCK SPECIFICATION
| ISUZU middle duty 8T flat bed rollback car carrier truck with 700P NPR full air brake chassis flat bed wrecker tow truck | ||||
| Vehicle parameters | ||||
| Vehicle Model | VLD51019TQZQ | Vehicle Brand | VELDLION | |
| Overall dimensions | 8429×2400×2420mm | Curb weight | 5960,6220kg | |
| Chassis parameters | ||||
| Chassis model | QL11019MARY | Chassis brand | ISUZU | |
| Overall dimensions | 7930X2170X2350mm | Wheel base | 4475mm | |
| Front/rear wheel track | 1680/1650mm | Front/rear suspension | 1110/2345mm | |
| Approach/departure angle | 21/11° | Maximum speed | 110km/h | |
| Chassis Manufacturer | QingLing Motors (Group) Co., Ltd. | |||
| Cab | Configuration | 700P,single row ,allowable 3 passengers,air conditioner, USB radio interface, cab can be flipped. | ||
| Color | White,other color is optional | |||
| Engine | Model | 4HK1-TCG40 | ||
| Emission | Euro 4 | |||
| Type | 4 cylinders,4 valve,4-stroke,in-line,common rail,precision electronic control,multistage injection,optimal combustion,exhaust gas recirculation, diesel engine. | |||
| Rated power | 190hp | |||
| Displacement | 5193ml | |||
| Manufacturer | Isuzu Engine (Chongqing) Co., Ltd. | |||
| Tire | Size | 8.25-20-14PR nylon tire | ||
| Number | 6+1 nos | |||
| Frame | 216X70(6+3)mm | |||
| Front axle | 4.0 tons | |||
| Rear axle | 7.0 tons | |||
| Drive form | 4X2 | |||
| Suspension | Multi leaf springs | |||
| Rated voltage | 24V,DC | |||
| Transmissions | Isuzu MLD six speed transmission, 6 speed forward 1 reverse. | |||
| Steering device | Power assisted steering | |||
| Steering wheel | Left hand drive | |||
| Selective configuration | Tire:825R16,825-20,825R20,235/75R17.5,a row and a half cab | |||
| Wrecker structure parameters | ||||
| Equipment | 2 units of towing wheel, 1 unit of 4 ton winch, 1 unit of steel wire rope, 1 unit of spare tire, 1 unit of jack, 1 unit of tire sleeve, 4 units of wrecker binding, 1 unit of alarm lamp. | |||
| Flat-bed dimensions | 5600*2400mm | |||
| Flat-bed Max capacity | 4000kg | |||
| Max under-hoisting capacity | 1800kg | |||
| Winch numbers | 1 unit | |||
| Max towing capacity of winch | 5000kg | |||
| Max towing speed | 40km/h | |||
| Length of steel wire rope | 20m | |||
| Speed of steel wire rope | 8 m/min | |||
» III. WRECK TOW TRUCK DESCRIPTION
» IV. WRECK TOW TRUCK TRANSPORTATION
» V. ABOUT US
» VII.OUR SERVICES
(1) More than 500 workers, large and advanced production;
(2) 25 professional engineers, can offer the best and cheapest design;
(3) Build strict QC team to guarantee the quality;
(4) 1 year or 30,000km warranty which comes first.
(5) One set of spare parts of chassis provided which will help you save money on maintenance.
(6) Provide technical support and after serive for life.
(7) Professional sales team which will help you to choose suitable truck.
» VII.FAQ
Why choose us?
Experience
10 years experience of production,sales,research and development in the field of special trucks.
Specialization
We can produce according to your demand, the material,the size, the color and the logo is optional for you.
Good quality
Has solid technology, advanced equipments;Reliant quality and flexible modes of operation also have strict quality control system and passed the iso9001-2008 and the 3c (china compulsory certification),with sgs,bv certifcate as well.
Chassis supply
We have a very good long term cooperation relationship with chassis manufacturer,such as dongfeng,foton,sinotruck,shacman,iveco,faw,hino,camc,north-benz,ect.
Production supply capacity
Company scale
More than 3000 employees with 1000 acres factory, total asset 2 billion.
We manufacture the truck as soon as possible once your order confirmed.And for the stock, we can delivery it immediately.
