Model NO.
WY5181TQZD
Fuel
Diesel
Bearing Capacity
Medium
Brand
FAW
Condition
New
Chassis Brand
Dongfeng, HOWO, Foton Aumark
Steering
LHD, Rhd, Left Hand Drive, Right Hand Drive
Cabin
2~3 Personn with A/C
Engine
141HP, Foton Cummins Diesel Engine
Wheel Base
1900+5600mm
Wrecker Type
One-Towing-One, One-Towing-Two
Flatbed Size
7200X2550mm
Max Lifting Weight
10 Tons; 12 Tons
Max Towing Weight
10tons; 12tons
Hydraulic System
Famous International Brand
Winch Rope
25m, 25meters
Key Features
Flatbed Full Landing.
Winch Capacity
10t, 10tons
Transport Package
Naked, Waxed, Bulk Ship, RO-RO
Specification
10T, 10ton, 10tons
Trademark
WEIYU
Origin
Suizhou, China
HS Code
8705909090
Production Capacity
500 Unit/Month
After-sales Service:
with After Sales Service
Warranty:
1 Year
Certification:
ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
Emission Standard:
Euro 3
Transmission Type:
Manual
Towing Tonnage:
10T
Multi-functional Dongfeng 10 Tons Flatbed Recovery Tow Truck Mounted with 6.3 Tons Crane
underlift boom of 10 tons flatbed recovery truck mounted with crane
Operation manual handles of 10 tons flatbed recovery truck mounted with crane
Checked plate of 10 tons flatbed recovery truck mounted with crane
Testing Photos for 10 Tons flatbed underlift tow truck in factory
10 tons flatbed road wrecker is optional for full landin/ground landed type wrecker
Except for whole road wrecker truck,we also customize road wrecker body for client according to truck chassis information in Australia,Chile,Argentina,USA and so on
Main Structure Diagram of flatbed road wrecker from WEIYU truck
For factory price and discount,contact us
1) flatbed tow truck with crane,also called platform road wrecker with crane,rollback tow truck,platform wrecker truck,rollback recovery truck,flatbed wrecker truck and so on.
2) Main Technical details of dongfeng 10 tons flatbed recovery truck with crane
- 10 ton flatbed loading capacity,
- 10 ton three-section split rear support arm,
- tail hydraulic turning plate,
- the board length is about 7.2 meters, the main board is about 6 meters, the tail The hydraulic turning plate is about 1.2 meters,
- plate width is 2.55 meters.
- 2 sets of fixed forks,
- a set of fork holders,
- 6 straps,
- additional air pipe joints,
- yellow warning lights,
- Equipped with 6.3-ton 4-section straight arm crane or 8-ton four-section straight arm crane (optional 16 thick manganese plate frame)
- Technical parameters: the height of the board from the ground is about 1.25 meters, the maximum load of the 10-ton top is about 12 tons, the curb weight is 12750kg or 13300kg, and the total mass is 18000kg.
underlift boom of 10 tons flatbed recovery truck mounted with crane
Operation manual handles of 10 tons flatbed recovery truck mounted with crane Checked plate of 10 tons flatbed recovery truck mounted with crane Testing Photos for 10 Tons flatbed underlift tow truck in factory
10 tons flatbed road wrecker is optional for full landin/ground landed type wrecker
Except for whole road wrecker truck,we also customize road wrecker body for client according to truck chassis information in Australia,Chile,Argentina,USA and so on
Product Specification of 4 tons road wrecker
| General Technical Parameters | |||
| Overall Dimension | 7800x2300x2530 (mm) | ||
| Gross Vehicle Weight | 10695kg | ||
| Curb Weight | 5695kg | ||
| Chassis Specification | |||
| Chassis Parameters | Chassis Brand | Sinotruk HOWO | |
| Cabin | 3 persons, Right Hand Driving for Botswana market, with air conditioner | ||
| Engine | Engine Brand | YUNNEI brand | |
| Model | YN4102QBZL, 4 Cylinders | ||
| Power | 85KW/116HP | ||
| Emission Standard | EURO III | ||
| Displacement | 3760ml | ||
| Fuel Type | Diesel | ||
| Gearbox | WLY646, Manual, 6 Forward & 1 Reverse Gear | ||
| Front and Rear Axle Load | 2.7T/7.2T | ||
| Wheel Base | 3800(mm) | ||
| Overhang( Front/Rear) | 1015/1815(mm) | ||
| Wheel track (front/rear) (mm) | 1504/1425 | ||
| Angle(Approach/departure) | 24/14(°) | ||
| Brake System | Air Brake | ||
| Steering Gear | Power Assistant | ||
| Tire | 7.50R16, 6 pieces+1 spare tire | ||
| Maximum Speed | 95(km/h) | ||
| Fuel tank | 120L | ||
| Superstructure | |||
| Flatbed | Dimensions | 5600(or 5800)x2250 (mm) | |
| Max. Loading Weight | 4000(kg) | ||
| Operating Stroke | 3700 (mm) | ||
| Min. Angle of Slope | 8(°) | ||
| Platform Height from the Ground | 1070(mm) | ||
| Winch | Quantity | 1pc | |
| Winch Rating Pulling Capacity | 4000(kg) | ||
| Length of Steel Cable | 20 (m) | ||
Main Structure Diagram of flatbed road wrecker from WEIYU truck
For factory price and discount,contact us
