Model NO.
IDL-VPL110
Design
Single Post
Certification
CE
Voltage
220V
Name
Loop Vehicle Detector(110)
Supply Voltage AC
220V, 110V, 24V, 12V
Supply Voltage DC
24V, 12V
Sensitivity
Adjustable in 3 Increments (High .Medium. Low)
Operating Temperature
-20 to +65 Degree
Storage Temperature
-40 to +85 Degree
Frequency Range
20 kHz to 170 kHz
Loop Connection Wiring
Maximum Length 200 Meters
shipment
by Air DHL, UPS, FedEx, TNT, by Sea, etc.
Transport Package
Standard Neutral Package or Customers Requirement
Specification
CE, Rohs
Trademark
IDL
Origin
China
HS Code
847190
Production Capacity
10000 Set / Month
Warranty:
at Least 1 Year
Type:
Parking Sensor
Working Mode:
Car Ride
Single channel inductive loop detectors; Adjustable in 3 increments (high. Medium. Low).
It is a single channel inductive loop detectors. The principle is based on a change in the inductance within the loop which is caused by the metallic components of passing vehicles. The changes are picked up and evaluated by a microprocessor. Ease of use due to the automatic calibration when the operating voltage is applied.
Technical Parameters
Supply voltage AC: 220V, 110V, 24V, 12V
Supply voltage DC: 24V, 12V
Sensitivity: Adjustable in 3 increments (high. Medium. Low)
Operating temperature: -20° C to +65° C
Storage temperature: -40° C to +85° C
Frequency range: 20 kHz to 170 kHz
Reaction time: 100ms
Loop inductance: Ideal: 80μ H to 300μ H
(incl. Conn. Wiring): Max: 50μ H to500μ H
Loop connection: <5m optimal
Loop connection wiring: Maximum length 200 meters
Twisted at least 20 times per meter
Dimensions: 36 X74X85 mm
It is a single channel inductive loop detectors. The principle is based on a change in the inductance within the loop which is caused by the metallic components of passing vehicles. The changes are picked up and evaluated by a microprocessor. Ease of use due to the automatic calibration when the operating voltage is applied.
Technical Parameters
Supply voltage AC: 220V, 110V, 24V, 12V
Supply voltage DC: 24V, 12V
Sensitivity: Adjustable in 3 increments (high. Medium. Low)
Operating temperature: -20° C to +65° C
Storage temperature: -40° C to +85° C
Frequency range: 20 kHz to 170 kHz
Reaction time: 100ms
Loop inductance: Ideal: 80μ H to 300μ H
(incl. Conn. Wiring): Max: 50μ H to500μ H
Loop connection: <5m optimal
Loop connection wiring: Maximum length 200 meters
Twisted at least 20 times per meter
Dimensions: 36 X74X85 mm
| Supply voltage AC | 220V, 110V, 24V, 12V |
| Supply voltage DC | 24V, 12V |
| Sensitivity | adjustable in 3 increments (high .medium. low) |
| Operating temperature | -20°C to +65°C |
| Storage temperature | -40°C to +85°C |
| Frequency range | 20 kHz to 170 kHz |
| Reaction time | 100ms |
| Loop inductance | Ideal:80μH to 300μH |
| (incl. conn. wiring) | max:50μH to500μH |
| Loop connection | <5m optimal |
| Loop connection wiring | Maximum length 200 meters |
| Twisted at least 20 times per meter | |
| Dimensions | 36 x74x85 mm |
