Model NO.
ERB20
Lift height
3000~5000mm
Condition
New
Rated Capacity
1400kg
Mast Extended Height
3725mm
Service Weight
720kg
Wheelbase
1115mm
Fork Carriage Width
800mm
Ground Clearance
25mm
Turning Radius
1788mm
Transport Package
Container
Specification
1724*800*2110mm
Trademark
LTMG
Origin
China
HS Code
8428109000
Production Capacity
800sets/Year
Cab Location:
Not Adjustable
Type:
Stacker
Power:
AC Motor
Load Capacity:
1T - 5T
Fuel:
Electric
Load center:
>500mm
China small electric stacker 1ton 2ton 3ton battery pallet stacker with ce
Product Features
The features of 0.5 ton electric stacker:
1. Germany system technology of warehousing equipment and leading international level.
2. The product with the principle of human engineering, fully humanized design.
3. Easy-controlling by operatior and flexible when carrying cargoes.
4. Using USA or Italy electronic assembly control, the German import control handle and Italy Metalrota driving wheel,and fully guarantee the stability of vehicle.
5. Newly designed by domestic well-known designer, with beautiful appearance.
The Specification of 1.4 ton Electric stachker
Packaging & Shipping
After-sale service
LTMG believes that after-sale service is as important as sale. And now we have more than 50 agents around the world to provide LTMG professional after-sale service.
All the product of LTMG supplied comes with one year or 2000 working hours (which occurs first) period quality warranty.
LTMG can also help clients coordinate with professional trained service engineer to provide you comprehensive knowledge about your machine. With our technical support, your machine service life can be significantly prolonged and sustained with high capacity.
Detail clauses and policies please check our website and product certificate.
Product Features
The features of 0.5 ton electric stacker:
1. Germany system technology of warehousing equipment and leading international level.
2. The product with the principle of human engineering, fully humanized design.
3. Easy-controlling by operatior and flexible when carrying cargoes.
4. Using USA or Italy electronic assembly control, the German import control handle and Italy Metalrota driving wheel,and fully guarantee the stability of vehicle.
5. Newly designed by domestic well-known designer, with beautiful appearance.
The Specification of 1.4 ton Electric stachker
| Distinguishing mark | ||||
| 1.1 | Manufacturer | LTMG | ||
| 1.2 | Model designation | ERB14 | ||
| 1.3 | Drive unit | Battery | ||
| 1.4 | Operator type | standing | ||
| 1.5 | rated capacity | Q | kg | 1400 |
| 1.6 | Load center distance | c | mm | 600 |
| 1.8 | Load distance,centre of drive axle to fork | x | mm | 690 |
| 1.9 | Wheelbase | y | mm | 1115 |
| Weight | ||||
| 2.1 | Service weight (include battery) | kg | 720 | |
| 2.2 | Axle loading, laden driving side/loading side | kg | 590/1510 | |
| 2.3 | Axle loading, unladen driving side/loading side | kg | 520/200 | |
| Types,Chassis | ||||
| 3.1 | Tyre type Driving wheels/Loading wheels | PU/PU | ||
| 3.2 | Tyre size, driving wheels(diameter×width) | mm | Ф 250×102 | |
| 3.3 | Tyre size, loading wheels(diameter×width) | mm | Ф85×95 | |
| 3.4 | Tyre size, caster wheels(diameter×width) | mm | Ф130×55 | |
| 3.5 | Wheels, number driving,caster/loading (x=drive wheels) | mm | 1x +1/2 | |
| 3.6 | Track width, front,driving side | b10 | mm | 539 |
| 3.7 | Track width,rear,loading side | b11 | mm | 436 |
| Dimensions | ||||
| 4.2 | Height, mast lowered | h1 | mm | 2110 |
| 4.3 | Free lift | h2 | mm | / |
| 4.4 | Lift height | h3 | mm | 3230 |
| 4.5 | Height, mast extended | h4 | mm | 3725 |
| 4.9 | Height drawbar in driving position min./max. | h14 | mm | 1150/1480 |
| 4.15 | Lowered height | h13 | mm | 88 |
| 4.19 | Overall length | l1 | mm | 1724 |
| 4.20 | Length to face of forks | l2 | mm | 574 |
| 4.21 | Overall width | b1 | mm | 800 |
| 4.22 | Fork dimensions | s/ e/ l | mm | 600×170×1150 |
| 4.24 | Fork carriage width | b3 | mm | 750 |
| 4.25 | Distance between fork-arms | b5 | mm | 600 |
| 4.32 | Ground clearance, center of wheelbase | m2 | mm | 25 |
| 4.34.1 | Aisle width for pallets 1000 × 1200 crossways | Ast | mm | 2670 |
| 4.34.2 | Aisle width for pallets 800 × 1200 lengthways | Ast | mm | 2640 |
| 4.35 | Turning radius | Wa | mm | 1788 |
| Performance data | ||||
| 5.1 | Travel speed, laden/ unladen | km/ h | 5.5/6 | |
| 5.2 | Lifting speed, laden/ unladen | m/ s | 0.12/0.26 | |
| 5.3 | Lowering speed, laden/ unladen | m/ s | 0.21/0.21 | |
| 5.8 | Max. gradeability, laden/unladen | % | 0.5 | |
| 5.10 | Service brake type | Electromagnetic | ||
| Electric-engine | ||||
| 6.1 | Drive motor rating S2 60 min | kW | 0.75 | |
| 6.2 | Lift motor rating at S3 15% | kW | 2.2 | |
| 6.3 | The maximum allowed size battery | mm | 262×165×170 | |
| 6.4 | Battery voltage/nominal capacity K5 | V/ Ah | 48/75 | |
| 6.5 | Battery weight | kg | 20×4 | |
| Addition data | ||||
| 8.1 | Type of drive unit | AC | ||
| 10.5 | Steering type | Mechanical | ||
| 10.7 | Sound pressure level at the driver's ear | dB (A) | 74 | |
Packaging & Shipping
About Us
After-sale service
LTMG believes that after-sale service is as important as sale. And now we have more than 50 agents around the world to provide LTMG professional after-sale service.
All the product of LTMG supplied comes with one year or 2000 working hours (which occurs first) period quality warranty.
LTMG can also help clients coordinate with professional trained service engineer to provide you comprehensive knowledge about your machine. With our technical support, your machine service life can be significantly prolonged and sustained with high capacity.
Detail clauses and policies please check our website and product certificate.
