Model NO.
FD20T
Fuel
Diesel
Load center
>500mm
Lift height
3000~5000mm
Condition
New
Transport Package
Nude Packing
Specification
2 ton
Trademark
LONKING
Origin
China
HS Code
842720900
Production Capacity
300pieces/Year
After-sales Service:
1 Year Warranty
Warranty:
1 Year Warranty
Cab Location:
Not Adjustable
Type:
Diesel Forklift
Power:
Diesel Engine
Load Capacity:
1T - 5T
China Professional Design Manual 2ton Diesel Forklift FD20T
1. New dynamic balancing design technology is adopted to make the center of gravity move backward, greatly improving the load capacity and the safety of load driving.
2. High flow cyclone air filter is perfectly combined with national III emission engine, Low noise, energy saving, environmental protection and greatly improve the efficiency of the whole machine.
3. The overhead guard is welded integrally, and the rear beam is fixed to reduce the vibration of the whole machine.
2. High flow cyclone air filter is perfectly combined with national III emission engine, Low noise, energy saving, environmental protection and greatly improve the efficiency of the whole machine.
3. The overhead guard is welded integrally, and the rear beam is fixed to reduce the vibration of the whole machine.
4. The design of the position of the joystick is more in line with ergonomic principle, which can reduce the fatigue of the driver Large-angle steering wheel and adjustable seat can meet different driving needs.
Digital instrument intelligence which is added the latest voice prompt.
5. The design of heat dissipation system and air duct is optimized to ensure the efficiency and energy saving of the whole machine.
6. The overall design of the frame is optimized and strengthened to reduce the vibration of the whole machine, enhance the strength of the frame and extend the service life of the whole machine.Product Parameters
model | FD20(T)II | |||||
Power form | diesel fuel | |||||
Rated load | kg | 2000 | ||||
Load center distance | mm | 500 | ||||
Lifting height | mm | 3000 | ||||
Free lift height | mm | 150 | ||||
Fork size | mm | 1070×120×40 | ||||
Mast inclination | you | 6 before 12 | ||||
Front overhang | mm | 460 | ||||
Overhang | mm | 410 | ||||
Dimensions | Total length | mm | 3590 | |||
Total width | mm | 1160 | ||||
The mast can't lift the height | mm | 2000 | ||||
Safety frame height | mm | 2110 | ||||
Block shelf (fork shelf) height | mm | 977 | ||||
Minimum turning radius | mm | 2200 | ||||
Minimum right-angle stacking channel width | mm | 3900 | ||||
Maximum travel speed (laden/unladen) | Km/h | 20/20 | ||||
Maximum lifting speed (no load/full load) | mm/s | 460/430 | ||||
Maximum grade | % | 20 | ||||
Self-respect | kg | 3600 | ||||
tire | Front wheel | 7.00-12-12PR | ||||
rear wheel | 6.00-9-10PR | |||||
Wheelbase | Front wheel | mm | 970 | |||
rear wheel | mm | 980 | ||||
Wheelbase | mm | 1650 | ||||
Minimum ground clearance | Door frame | mm | 110 | |||
Frame | mm | 140 | ||||
rated power | kw | 39 | 36.8 | |||
Fuel tank capacity | ltr | 50 | 50 | |||
