Model NO.
FD30
Condition
New
Engine
China / Japan for Choice
Mast
Duplex/Full Free Lift Mast
Options
LED Light, Lux Seat, Fan, Solid Tire Ect
Transmission
Automatic Transmission
Attachements
Side Shifter, Clamps, Positioner Ect
Tires
Pneumatic Tire
Color
Cumtomer Cutomized
OEM
Yes
Transport Package
Container Shipment
Specification
4250kg
Trademark
SNSC
Origin
China, Wuhu
HS Code
84272090
Production Capacity
15000pieces/Years
Cab Location:
Adjustable
Type:
Container Forklift
Power:
Diesel Engine
Load Capacity:
1T - 5T
Fuel:
Diesel
Load center:
>500mm
| Specifications | Unit | FD30 | |||
| 1 | Characteristics | Power | diesel | ||
| 2 | Rated Capacity | kg | 3000 | ||
| 3 | Center of load | mm | 500 | ||
| 4 | Lifting height | mm | 3000 | ||
| 5 | Free lifting height | mm | 145 | ||
| 6 | Forks L×W×H | mm | 1070×125×45 | ||
| 7 | Tilt Forward/Backward | . | 6/12 | ||
| 8 | Min.turning radius | mm | 2600 | ||
| 9 | Min.ground clearance(Mast) | mm | 120 | ||
| 10 | Overhead guard height | mm | 2170 | ||
| 11 | Height from seat to overhead guard | mm | 480 | ||
| 12 | Front overhang | mm | 545 | ||
| 13 | Perf | Max.traveling speed(loaded) | km/h | 20 | |
| 14 | Max.lifting speed(loaded/empty) | mm/s | 470/520 | ||
| 15 | Drawbar pull/Gradeability | kN/% | 18/20 | ||
| 16 | Dimensions | Overall length (without fork) | mm | 2825 | |
| 17 | Overall width | mm | 1230 | ||
| 18 | Mast lowered height | mm | 2065 | ||
| 19 | Mast extended height | mm | 4260 | ||
| 20 | Chassis | Tire | Front | 28×9-15-12PR | |
| 21 | Rear | 6.50-10-10PR | |||
| 22 | Wheelbase | mm | 1800 | ||
| 23 | Tread width | Front/Rear | mm | 1000/970 | |
| 24 | Curb weight | None-load | kg | 4250 | |
| 25 | Powertrain | Battery | Voltage/Capacity | V/Ah | 12/90 |
| 26 | Engine | Model | QC490GP | ||
| 27 | Rated power | kw/r.p.m | 39/2650 | ||
| 28 | Rated torque | Nm/r.p.m | 157/1980 | ||
| 29 | Cylinder amount | 4 | |||
| 30 | Bore×Stroke | mm | 90×105 | ||
| 31 | Displacement | 2.67 | |||
| 32 | Fuel tank | L | 70 | ||
| 33 | Transmission | 1/1 automatic transmission | |||
| 34 | Working pressure | MPa | 17.5 | ||
As for the detailed humanization design, this is the waterproof overheard guard, steel structure lights protection guard, here is tilting cylinder protection cover for anti-dust, and here, copper radiator in cooling system.
The shipping terms depends on quantity. If 1 Set we choose LCL in Shanghai Port;if 2 Sets and More, we choose shipping by Full Container 20'GP can hold 2 Sets, If you need, you can also choose RO-RO shippment.
We SNSC forklift can be customized, side shifter, fork positioner, cabin, all kinds of attachments, such as paper roll clamp, bale clamp, block clamp, carton clamp, and so on.
We have all kinds of forklift , here is our forklift catalogue for your choice:
1)Diesel forklift truck capacity from 1.5ton to 16ton;
2) Electric forklift truck capacity from 1.5ton to 3.5ton;
3) LPG gas gasoline forklift truck capacity from 1.5ton to 7ton;
4) Warehouse equipment, includes electric pallet truck, electric reach truck, electric stacker, electric trailer
5) Rough terrain forklift truck capacity from 1.8-5ton;
5) Other special function forklift, eg: cold warehouse electric forklift, explosion-proof forklift, renting business forklift.
