Model NO.
HH30Z
Fuel
Diesel
Load center
500mm
Lift height
3000~5000mm
Condition
New
Fork Size (L× W× T)
1070X125X45mm
Engine
Xinchai C490bpg
Rated Output
37kw
Transmission
Hydraulic
Transport Package
Standard Package
Specification
3 ton
Trademark
HUAHE
Origin
Zhejiang, China
HS Code
84272090
Production Capacity
20 Sets/Month
After-sales Service:
Spare Parts Free
Warranty:
One Year Warranty
Cab Location:
Adjustable
Type:
Powered Pallet Truck
Power:
Diesel Engine
Load Capacity:
1T - 5T
HUAHE 3ton Diesel Forklift HH30Z with 4m Mast
Characteristics:
•High-end technical equip more perfect and high quality, the comfortable operation ...
•Simple comfortable operating system, the steering wheel be possible to adjust
•A broad operation field of vision
•Gate angle for the anteversion 6 degree caster 12 degrees...
•The stable antivibration device, around adjust chair user friendly design
Parameters:
Characteristics:
•High-end technical equip more perfect and high quality, the comfortable operation ...
•Simple comfortable operating system, the steering wheel be possible to adjust
•A broad operation field of vision
•Gate angle for the anteversion 6 degree caster 12 degrees...
•The stable antivibration device, around adjust chair user friendly design
Parameters:
| Generals | Model | Unit | HH30Z | ||
| Power type | Diesel | ||||
| Rated capacity | Kg | 3000 | |||
| Load center | mm | 500 | |||
| Dimensions | Lift height | mm | 4500 | ||
| Free lift height | mm | 142 | |||
| Fork size (L× W× T) | mm | 1070× 125× 45 | |||
| Mast inclination F/R | Deg | 6° /12° | |||
| Front overhang | mm | 497 | |||
| Overall Dimensions | Length to face of fork | mm | 2680 | ||
| Overall width | mm | 1225 | |||
| Mast lowered height | mm | 2095 | |||
| Overhead guard height | mm | 2120 | |||
| Turning radius | mm | 2460 | |||
| Min. right angle aisle width | mm | 2105 | |||
| Performance | Travel speed | Unload I/II | Km/h | 9/20 | |
| Full load I/II | Km/h | 8.8/19.5 | |||
| Lift speed | mm/s | 400 | |||
| Max. grade ability | % | 20 | |||
| Max. drawbar pull | Kn | 13.5 | |||
| Self weight | Kg | 4900 | |||
| Wheels & Tires | Tires | Front | 28x9-15-12PR | ||
| Rear | 6.50-10-10PR | ||||
| Tread | Front Q | mm | 1000 | ||
| Rear S | mm | 970 | |||
| Wheelbase | mm | 1700 | |||
| Min. ground clearance (unload/full load) | Mast | mm | 152/110 | ||
| Frame | mm | 166/160 | |||
| Drive units & Control | Battery | V/Ah | 12/105 | ||
| Engine | Model | XINCHAI C490BPG | |||
| Rated output | Kw/rpm | 37/2650 | |||
| Rated torque | N. m/rpm | 148/1800 | |||
| Displacement | cc | 2540 | |||
| Transmission | Type | Hydraulic | |||
| Shift Fwd/Rwd | 1/1 Power shift | ||||
| Operating pressure | Mpa | 17.5 | |||
