Condition
New
Bucket
0.8cbm
Transport Package
Nude Makeup
Specification
steel
Trademark
FENDOU
Origin
China
Production Capacity
10000piece/Year
Cab Location:
Adjustable
Power:
Diesel Engine
Load Capacity:
10T - 18T
Fuel:
Diesel
Load center:
>500mm
Lift height:
3000~5000mm
High Quality DOOXIN Excavator/Mechanical Digger/Excavating Machine DOOSAN TECHNOLOGY For River/Lake/Port Use
We can provide:
TRUCK
Sales Chinese trucks and construction machinery, Provide modificationsu, pgrades, consulting services
SPARE PARTS
Supply China Truck spare parts and construction machinery parts. Products Include: Sinotruk HOWO, Weichai Power, Fonton, Shacman, SHANTUI, SDLG
SERVICE
Provide cargo warehousing, packaging, shipping and export agency services
Agent procurement, inspection The inspection agency
Exclusive highly efficient hydraulic
control system
Engine: ISUZ U or Cummins
Main pump: Kawasaki
Control valve: Kawasaki or Parker, optional
Travel motor: Sunjin (Korea)
Swing motor: Sunjin (Korea)
Powerful travel traction
Effectively prevent mixing of soil and
rock
Highly efficient and rapid operations
High-strength frame structure and
greater ground clearance
Safe and open engine hood
Convenient and swift maintenance
Parameter configuration of Doosan DX230 excavator
Parameter configuration of Doosan DX230 excavator
| PARAMETERS FOR DOOXIN DX150PC-9 EXCAVATOR | ||
| MODEL | DX150PC-9 | |
| Performance parameters | ||
| 1 | Operating weight | 14800kg |
| 2 | Bucket capacity | 0.53-0.58m3 |
| 3 | Engine rated power | 73kw/1850rpm |
| 4 | Swing speed | 10.1Min |
| 5 | Travel speed (high/low) | 5.04/3.01kmh |
| 6 | Ground specific pressure | 35-36KPa |
| 7 | Gradeability | 70 |
| 8 | Digging force | 77.4KN/Turbo 81.3KN |
| 9 | Boom length (mm) | 4600mm |
| 10 | Arm length (mm) | 2500mm |
| Working Range | ||
| 11 | Maximum digging depth | 5625mm |
| 12 | Maximum digging height | 8750mm |
| 13 | Maximum unloading height | 8300mm |
| 14 | Maximum digging radius | 8160mm |
| 15 | Minimum turning radius | 2207mm |
| Dimensions | ||
| a | Transport length | 7662mm |
| b | Transport arm height | 2980mm |
| c | Wheelbase | 2780mm |
| d | Radius of gyration platform end | 2202mm |
| e | Counter weight ground clearance | 894mm |
| f | Track Gauge | 1990mm |
| g | Total width of undercarriage | 2590mm |
| h | Width of upper structure | 2540mm |
| i | Width of track shoe | 600mm |
| j | Ground clearance | 412mm |
| k | Total length of travel section | 3750mm |
| l | cabin height | 832mm |
Doosan dx150, as a new upgrade product of Doosan construction machinery's classic excavator dh300-7, has been upgraded to a large extent in many parts and configurations.
Increased comfort and controllability
In addition to the new high-quality seats, the enhanced cab offers more standard features than other machines on the market, ensuring superior controllability and high accuracy in all applications.
Main construction machine we can provide
Bulldozer, wheelloader,excavator
We can provide: TRUCK
Sales Chinese trucks and construction machinery, Provide modificationsu, pgrades, consulting services
SPARE PARTS
Supply China Truck spare parts and construction machinery parts. Products Include: Sinotruk HOWO, Weichai Power, Fonton, Shacman, SHANTUI, SDLG
SERVICE
Provide cargo warehousing, packaging, shipping and export agency services
Agent procurement, inspection The inspection agency
