Model NO.
FD50
Fuel
Diesel
Load center
500mm
Lift height
3000~5000mm
Condition
New
Engine
Chinese Engine
Color
Could Be Designed by Buyer
Optional
Solid Tires, Side Shift, Three Stage Mast, etc
Attachment
Paper Roll Clamp, Bale Clamp, Crane. etc
Transport Package
Export Package
Specification
3455*1995*2500 mm
Trademark
TDER
Origin
China
HS Code
842710900
Production Capacity
1000 Units/Year
After-sales Service:
1 Year or 2000 Working Hours Which Ever Comes Firs
Warranty:
1 Year / 2000 Working Hours
Cab Location:
Not Adjustable
Type:
Diesel Forklift
Power:
Diesel Engine
Load Capacity:
5T - 10T
Product Specification
| Model | FD20 | FD40 | FD50 | FD60 | |
| Load Centre | 500mm | 500mm | 600mm | 600mm | |
| Load capacity | 2000kg | 4000kg | 5000kg | 6000kg | |
| Mast | 2-stage-mast | 2-stage-mast | 2-stage-mast | 2-stage-mast | |
| Fork size | 1070×120×40 | 1070×150×50 | 1070×150×50 | 1220×150×60 | |
| Engine | Quanchai | Quanchai | Quanchai | Quanchai | |
| Tire | Front | 7.00-12-12PR | 300-15-18PR | 300-15-18PR | 8.25-15-14PR |
| Rear | 6.00-9-10PR | 7.00-12-12PR | 7.00-12-12PR | 8.25-15-14PR | |
| Length to face of fork | 2595mm | 3260mm | 3260mm | 3440mm | |
| Overall Width | 1150mm | 1460mm | 1460mm | 2010mm | |
| Overhead Guard Height | 2070mm | 2340mm | 2340mm | 2430mm | |
| Model | FD70 | FD80 | FD100 | FD120 | |
| Load Centre | 600mm | 600mm | 600mm | 600mm | |
| Load capacity | 7000kg | 8000kg | 10000kg | 12000kg | |
| Mast | 2-stage-mast | 2-stage-mast | 2-stage-mast | 2-stage-mast | |
| Fork size | 1220×150×70 | 1220×150×70 | 1520×175×85 | 1520×180×100 | |
| Engine | Quanchai | Quanchai | Quanchai | Yuchai | |
| Tire | Front | 8.25-15-14PR | 8.25-15-18PR | 9.00-20-14PR | 10.00-20-18PR |
| Rear | 8.25-15-14PR | 8.25-15-18PR | 9.00-20-14PR | 9.00-20-18PR | |
| Length to face of fork | 3565mm | 3565mm | 4280mm | 4685mm | |
| Overall Width | 2010mm | 2010mm | 2170mm | 2200mm | |
| Overhead Guard Height | 2430mm | 2430mm | 2510mm | 2540mm | |
