Model NO.
SES10
Fuel
Electric
Load center
500mm
Lift height
1600-3000mm
Condition
New
Material
Steel
Fork Size
910/1150mm Length
Application
Indoor, Outdoor Warehouse, Supermarket, etc
Service
OEM, ODM Service
Certification
CE,ISO9001,ISO14001
Transport Package
in Pallet with Necessary Protection
Specification
1585x1045x2000mm
Trademark
FUPIA
Origin
China
HS Code
8427109000
Production Capacity
30000units/Year
After-sales Service:
7 Day X 24 Hours Online Service
Warranty:
1 Year
Cab Location:
Not Adjustable
Type:
Stacker
Power:
DC Motor
Load Capacity:
1000kgs
FUPIA stackers is designed for warehouse material handling in industrial and manufacturing environments.Our semi-electric models combine manual traction and electric elevation. This is the ideal solution for moving medium-light loads.
- The masts are designed to maximize view of the forks during operation making it easy for operators to maneuver safely.
- Durable mast rollers and wire mesh safety guard.
- Explosion-proof valve, against of sudden drop of forks and prevent operator from harm.
- Rugged steel with heavy duty floor lock.
- Wide and high stabilities straddle leg ensures rigidity and durabilities.
- Over-discharge protection device greatly prolongs the battery life time.
- The oil-reflow valve for safe operation.
| 1 | Brand | FUPIA | |||
| 2 | Model | SES10 | SES15 | SES20 | |
| 3 | Power Type | Electronic | |||
| 4 | Rated Load Capacity | Q(kg) | 1000 | 1500 | 2000 |
| 5 | Load Centre | C(mm) | 480 | ||
| 6 | Lift Height | H(mm) | 1600/2000/2500/3000 | ||
| 7 | Fork Size (Length) | mm | 910(1150) | ||
| 8 | Fork adjustable width | mm | 320-680 | ||
| 9 | Overall Length | mm | 1585 | ||
| 10 | Overall Width | mm | 1045 | ||
| 11 | Turning radius | km/h | 1480 | ||
| 12 | Lifting Speed (No Load/Full Load) | mm/sec | 120/100 | ||
| 13 | Lowering Speed (No Load/Full Load) | mm/sec | 130/150 | ||
| 14 | Lifting motor | V/A | 12/1.6 | ||
| 15 | Battery | V/AH | 12/120 | ||
| 16 | Charger | V/AH | 12/18 | ||
