Model NO.
FD25T
Fuel
Diesel
Load center
500mm
Lift height
3000
Condition
New
Free Lifting Height
140mm
Max.Gradeability Loaded
21%
Turning Radius
2210mm
Lifting Speed Loaded
560mm
Engine
Xinchai/Mitsubishi
Weight
3765kg
Rated Capacity
2500kg
Fork Size
1220X122X40mm
Transmission Box Type
Automatic Transmission
Tire Type
Pneumatic Tire
Transmission
Hydraulic
Optional
Attachment, Side Shifter, Sealed Cab, Mast, etc
Mast
Duplex Mast (Triplex Mast Optional)
Color
Customized
Certification
CE/ISO
Transport Package
Container
Specification
2605x1150x2090mm(LXWXH)
Trademark
Hifoune
Origin
Xiamen, China
HS Code
8427109000
Production Capacity
4500sets/Year
After-sales Service:
Video Technical Support
Warranty:
One Year or 2000hours
Cab Location:
Adjustable
Type:
Diesel Forklift
Power:
Diesel Engine
Load Capacity:
2t-2.5t
2T 2.5T Fully Hydraulic Balanced Mini Diesel XINCHAI MITSUBISHI Japanese Engine Forklift with Various Fork Types
Forklift truck are industrial vehicles, which refer to various wheeled handling vehicles for loading, unloading, stacking and short-distance transportation of palletized goods. The International Organization for Standardization ISO/TC110 is called an industrial vehicle. It is often used for the transportation of large objects in storage, and is usually driven by fuel engines or batteries.The technical parameters of the forklift are used to indicate the structural characteristics and working performance of the forklift. The main technical parameters are: rated lifting capacity, load center distance, maximum lifting height, mast angle, maximum travel speed, minimum turning radius, minimum ground clearance, wheelbase, wheelbase, etc.
Specification
| Model | UNIT | FD20T | FD25T | FD30T | FD35T | FD40T |
| Power Unit | Diesel | Diesel | Diesel | Diesel | Diesel | |
| Transmission Type | Electronic hydraulic | Electronic hydraulic | Electronic hydraulic | Electronic hydraulic | Electronic hydraulic | |
| Rated Capacity | kg | 2000 | 2500 | 3000 | 3500 | 4000 |
| Load Center | mm | 500 | 500 | 500 | 500 | 500 |
| MaX.Lifting Height | mm | 3000 | 3000 | 3000 | 3000 | 3000 |
| Turning Radius | mm | 2170 | 2240 | 2400 | 2460 | 2560 |
| Overall Length (without fork) | mm | 2605 | 2605 | 2705 | 2760 | 2820 |
| Overall Width | mm | 1150 | 1150 | 1240 | 1240 | 1300 |
| Overhead Guard Height | mm | 2090 | 2090 | 2130 | 2130 | 2130 |
| Fork Size (L×W×T) | mm | 1220×122×40 | 1220×122×40 | 1220×125×45 | 1220×125×50 | 1220×150×50 |
| Mast Height (Fork lowered) | mm | 2090 | 2090 | 2140 | 2140 | 2140 |
1.Adopt gradeability improving style electronic hydraulic transmission, compare with other models: efficiency 5% improved, climbing torque 8% increased, noise 3~5dB reduced, thermal equilibrium temperature 8-10decreased.
2.Load sensing priority steering hydraulic system is adopted to reduce pressure loss of hydraulic system, save energy and improve operation comfort.
3.Introducing advances technology from Germany, the unique single chain has greatly enhanced he front view while working.
4.The new suspension system, adjustable seat, allowing the driver to feel more comfortable and reducing fatigue during long operations.
