Model NO.
ES10-10ESJ
Lift height
3000~5000mm
Condition
New
Name
1.0 Ton Electric Pallet Stacker (Es10-10esj)
Drive Unit
Electric
Rated Capacity
1000kg
Power Source
Electric
Service Weight
511kg
Lifting Height
3000mm
Overall Length
1740mm
Overall Width
800mm
Fork Size
55/160/1150mm
Transport Package
Seaworthy Packing
Specification
CE, SGS, ISO
Trademark
SHYTGER
Origin
Shanghai, China
HS Code
84271090
Production Capacity
3000units/Year
Cab Location:
Stand
Type:
Powered Pallet Truck
Power:
AC Motor
Load Capacity:
1.5ton
Fuel:
Electric
Load center:
600mm
1.0 Ton Electric Pallet Stacker (ES10-10ESJ)
Characteristics:
1. Emergency reversing device.
2. Built-in pressure relief valve protects the trucks from overloads.
3. Emergency power disconnect.
4. Low speed switch in the handle.
5. Stepless speed control.
6. The rubber platform and safety guides increase operator safety and reduce fatigue, and they can be folded away when not in use
7. Imported hydraulic pump station makes the lifting of goods steady and powerful.
8. Compact structure, solid carriage and large capacity
1.Good Looking Appearence,Strong Stucture
2.Emergency Button For Safety
3.Easy To Operate
4.Motor Cover
5.Long Life Rechargeable Batteries
6.Voltage Of Phase,Hertz, Ampere etc Can be Customized
7.SME/ZAPI/CURTIS AC power controller
FAQ:
Characteristics:
1. Emergency reversing device.
2. Built-in pressure relief valve protects the trucks from overloads.
3. Emergency power disconnect.
4. Low speed switch in the handle.
5. Stepless speed control.
6. The rubber platform and safety guides increase operator safety and reduce fatigue, and they can be folded away when not in use
7. Imported hydraulic pump station makes the lifting of goods steady and powerful.
8. Compact structure, solid carriage and large capacity
1.Good Looking Appearence,Strong Stucture
2.Emergency Button For Safety
3.Easy To Operate
4.Motor Cover
5.Long Life Rechargeable Batteries
6.Voltage Of Phase,Hertz, Ampere etc Can be Customized
7.SME/ZAPI/CURTIS AC power controller
Basic Parameter | |
Item No: ES10-10ESJ | |
Press capacity: 1000kg | |
Control system: CURTIS | |
Battery voltage: 24V/ 85Ah | |
Load center: 600mm | |
Operate type: pedestrian | |
Forks dimension: 55/160/1150mm | |
Overall Dimension: 1740*800*2022mm | |
Structure Weight: 511kg | |
HS Code: 84271090 | |
Some spare parst free for you. | |
Attention: | |
1.Max lift height can be 5500mm available. | |
2.Local voltage can be customized. | |
3.Blue light can be added like forklift. | |
4.Spare parts available. | |
5,All colors are available. | |
Remarks: | |
1.Trade terms:FOB,CFR,CIF are available. | |
2.Delivery time:within 25 received payment. | |
3.Packing:Pallet packing,spare parts is packed in a box. | |
4.Warranty:2000 working hours or 12month. | |
Characteristics | |||
1.1 | Manufacturer | HYTGER | |
1.2 | Model designation | ES0-10ESJ | |
1.3 | Drive unit | Battery | |
1.4 | Operator type | Walkie | |
1.5 | Load capacity | Q (kg) | 1000 |
1.6 | Load center | c (mm) | 600 |
1.9 | Wheelbase | y (mm) | 1240 |
Weights | |||
2.1 | Service weight (Incl. battery) | kg | 511 |
2.2 | Axle loading, laden operator/load side | kg | 653/858 |
2.3 | Axle loading, unladen operator/load side | kg | 386/125 |
Wheels, Chassis | |||
3.1 | Tyre type | PU/ PU | |
3.2 | Tyre size, operator side | mm | 210× 70 |
3.3 | Tyre size, load side | mm | 80× 60 |
3.4 | Balance wheels (dimensions) | mm | 130×55 |
3.5 | Wheels, number operator/load side (x=drive wheels) | 1x+ 0/ 4 | |
3.6 | Tread, operator side | b10 (mm) | 533 |
3.7 | Tread, load side | b11 (mm) | 400 |
Dimensions | |||
4.2 | Height, mast lowered | h1 (mm) | 2022 |
4.3 | Free lift | h2 (mm) | 150 |
4.4 | Lift height | h3 (mm) | 2930 |
4.5 | Height, mast extended | h4 (mm) | 3487 |
4.9 | Height of straddle arms or load wheel casing | h8 (mm) | 88 |
4.15 | Fork height, lowered | h13 (mm) | 88 |
4.19 | Overall length | l1 (mm) | 1740 |
4.20 | Length to face of forks | l2 (mm) | 590 |
4.21 | Overall width | b1/ b2 (mm) | 800 |
4.22 | Fork dimensions | s/ e/ l (mm) | 55/160/1150 |
4.24 | Width of fork frame | b3 (mm) | 600 |
4.25 | Outside fork width, minimum/ maximum | b5 (mm) | 560 |
4.26 | Inner width of leg | b4 (mm) | 970/1270 |
4.32 | Ground clearance | m2 (mm) | 30 |
4.33 | Aisle width, 1000×1200 pallet crossways | Ast (mm) | 2225 |
4.34 | Aisle width, 800×1200 pallet lengthways | Ast (mm) | 2150 |
4.35 | Outer turning radius | Wa (mm) | 1408 |
Performance | |||
5.1 | Travel speed, laden/ unladen | km/ h | 3.5/4 |
5.2 | Lifting speed, laden/ unladen | m/ s | 0.12/ 0.22 |
5.3 | Lowering speed , laden/ unladen | m/ s | 0.12/0.11 |
5.8 | Maximum gradeability, laden/ unladen S2 5 min. | % | 3/10 |
5.10 | Service brake | Electromagnetic | |
Drive | |||
6.1 | Drive motor rating S2 60 min. | kW | 0.65 |
6.2 | Lift motor rating at S3 15% | kW | 2.2 |
6.4 | Battery voltage/ rated capacity (5h) | V/ Ah | 24/ 85 |
6.5 | Battery weight (with box) | kg | 2×25 |
Others | |||
8.1 | Type of drive control | ZAPI DC | |
8.4 | Sound level at operator's ear | dB (A) | 74 |
FAQ:
1.Any Gurantee Of Stackers? | |||||||
One Year or 2000 working hours after received stackers | |||||||
2.Can you supply operation manual? | |||||||
Yes. | |||||||
3.Can you supply the spare parts? | |||||||
Yes,of course.if you order 1unit,we can supply some for free. | |||||||
4.What Kind of Payment you can accept? | |||||||
T/T,L/C,Western Union,Paypal etc. |
