Model NO.
CPD10-18
Lift height
>5000mm
Condition
New
Colour
4
Powe
Elecric /Battery
Liftheight
3000-6000
Controller
Curtis
Motorac/DC
AC*/DC
Battery
46/600*80/500
Tyir
Solid
Forksize
1070-1220mm
Wheel
Four Wheel
Load Centre
500
Transport Package
Nude Packing
Specification
electric
Trademark
GP
Origin
China
HS Code
8427209000
Production Capacity
3000 Units Year
Cab Location:
Adjustable
Type:
Electric Forklift
Power:
AC Motor
Load Capacity:
1T - 5T
Fuel:
Electric
Load center:
>500mm
1. Model No: CPD10-18
2. Rated Capacity: 2.5 T
3. Lift Height: 3000mm dual mast
4. Type: Electric forklift truck
5. Large capacity battery and charger included
6. Can work inside cold warehouse
We are the professional manufacturer of material handling equipment in china. We can produce the forkift ranging from 1 ton to15ton, welcome to contact us for inquiry.
Italy SME AC control system
Easy-to-read multifunction display panel
Imported fully AC motor and hydraulic
Chinese famous brand forklift truck
2. Rated Capacity: 2.5 T
3. Lift Height: 3000mm dual mast
4. Type: Electric forklift truck
5. Large capacity battery and charger included
6. Can work inside cold warehouse
We are the professional manufacturer of material handling equipment in china. We can produce the forkift ranging from 1 ton to15ton, welcome to contact us for inquiry.
Italy SME AC control system
Easy-to-read multifunction display panel
Imported fully AC motor and hydraulic
Chinese famous brand forklift truck
| General | Manufacturer | GP | ||||||||||
| 1 | Model | CPD10 | CPD15 | CPD18 | ||||||||
| 2 | Rated capacity | kg | 1000 | 1500 | 1800 | |||||||
| 3 | Load center | mm | 500 | |||||||||
| 4 | Power type | Battery | ||||||||||
| 5 | Tire type | Front/Rear | Pneumatic | |||||||||
| 6 | Wheels | Front/Rear | 2*2 | |||||||||
| Dimensions | 7 | Lift height | mm | 3000 | ||||||||
| 8 | Free lift height | mm | 140 | 145 | ||||||||
| 9 | Fork size | L*W*T | mm | 920*100*35 | 920*100*35 | |||||||
| 10 | Mast tilt angle | Fwd/Bwd | deg | 6/12 | 6/12 | |||||||
| 11 | Overall length (without fork) | mm | 1056 | 1056 | 24056 | |||||||
| 12 | Overall width | mm | 1090 | 1090 | ||||||||
| 13 | Mast height fork lowered | mm | 2015 | 2015 | ||||||||
| 14 | Overall height fork raised | mm | 4040 | 4273 | ||||||||
| 15 | Overall height (overhead guard) | mm | 2159 | 2125 | ||||||||
| 16 | Turning radius (outside) | mm | 2050 | 2100 | 2230 | |||||||
| 17 | Load distance (centerline of front axle to front face of forks) | mm | 479 | 484 | 454 | |||||||
| 18 | Minimum Aisle -90 degree stack(Add load length and clearance) | mm | 4160 | 4360 | 4850 | |||||||
| 19 | Wheel base | mm | 1380 | 1380 | ||||||||
| 20 | Tread | Front | mm | 960 | 1040 | |||||||
| 21 | Rear | mm | 950 | 980 | ||||||||
| 22 | Min. Under-clearance | Bottom of mast | mm | 100/120 | 85/105 | |||||||
| 23 | Bottom of frame | mm | 100/120 | 120/140 | ||||||||
| Performance | 24 | Speed | Travel Max. | With load | km/h | 11 | 10.5 | 12 | ||||
| 25 | Without load | km/h | 12.5 | 12.5 | 13 | |||||||
| 26 | Lifting | With load | km/h | 260 | 250 | 250 | ||||||
| 27 | Without load | km/h | 400 | 390 | 380 | |||||||
| 28 | Max. Drawbar pull | With/without load | Kn | 8 | 8 | 10 | ||||||
| 29 | Max.Gradeability | With/without load | % (fan) | 10 | 10 | |||||||
| Weight | 30 | Service weight | kg | 4160 | 4360 | 4850 | ||||||
| Tyre | 31 | Tyre | Size | Front | 7.00-12-12PR | 23*9-10 | ||||||
| 32 | Rear | 18*7-8-14PR | 18*7-8 | |||||||||
| power control | 33 | Battery | Voltage | V | 48 | 80 | ||||||
| 34 | Capacity | AH | *630/700 | *500/600 | ||||||||
| 35 | Hyfraulic motor | drive motor | kw/rpm | 7.0/1400 | 10.2/1500 | |||||||
| 36 | lift motor | kw | 8.6/1600 | 10/2000 | ||||||||
| 37 | controller | CURTIS controller | ||||||||||
