Model NO.
EPT20-15ET
Lift height
115mm
Condition
New
Rated Loading Capacity
1500kg
Fork Length
1150mm
Fork Width
150mm
Overall Width
560/685mm
Lowered Height
85/75mm
Service Weight
205kg
Battery Voltage
85ah/24V
Certification
Ce/ISO9001
Wheelbase
1228/1268mm
Ground Clearance
35/25mm
Turing Radius
1485mm
Transport Package
Standard Export Package
Specification
1632*560*1170mm
Trademark
EP
Origin
Zhengjiang, China
HS Code
8427109000
Production Capacity
5000 Units/Year
Cab Location:
Pedestrian
Type:
Powered Pallet Truck
Power:
DC Motor
Load Capacity:
1500kg
Fuel:
Electric
Load center:
600mm
| Distinguishing mark | ||||
| 1.1 | Manufacturer | EP | ||
| 1.2 | Model designation | EPT20-15ET | ||
| 1.3 | Drive unit | Electrics | ||
| 1.4 | Operator type | pedestrian | ||
| 1.5 | rated capacity | Q | kg | 1500 |
| 1.6 | Load center distance | c | mm | 600 |
| 1.8 | Load distance | x | mm | 883/946 |
| 1.9 | Wheelbase | y | mm | 1228/1268 |
| Weight | ||||
| 2.1 | Service weight (include battery) | kg | 205 | |
| 2.2 | Axle loading, laden driving side/loading side | kg | 574/1131 | |
| 2.3 | Axle loading, unladen driving side/loading side | kg | 165/40 | |
| Types,Chassis | ||||
| 3.1 | Tyre type driving wheels/loading wheels | PU/ PU | ||
| 3.2 | Tyre size, driving wheels(diameter×width) | mm | Ф210x70 | |
| 3.3 | Tyre size, loading wheels(diameter×width) | mm | 2x Ф80x60(Ф74x88) | |
| 3.4 | Tyre size, caster wheels(diameter×width) | mm | Ф74x48 | |
| 3.5 | Wheels, number driving,caster/loading (x=drive wheels) | mm | 1x 2/4(1x 2/2) | |
| 3.6 | Track width, front,driving side | b10 | mm | 432 |
| 3.7 | Track width,rear,loading side | b11 | mm | 410(535) |
| Dimensions | ||||
| 4.4 | Lift height | h3 | mm | 115 |
| 4.9 | Height drawbar in driving position min./max. | h14 | mm | 750/1170 |
| 4.15 | Lowered height | h13 | mm | 85(75) |
| 4.19 | Overall length | l1 | mm | 1632 |
| 4.20 | Length to face of forks | l2 | mm | 482 |
| 4.21 | Overall width | b1/ b2 | mm | 560(685) |
| 4.22 | Fork dimensions | s/ e/ l | mm | 50/150/1150 |
| 4.25 | Outside width of the forks | b5 | mm | 560(685) |
| 4.32 | Ground clearance, center of wheelbase | m2 | mm | 35(25) |
| 4.34.1 | Aisle width for pallets 1000 × 1200 crossways | Ast | mm | 1739 |
| 4.34.2 | Aisle width for pallets 800 × 1200 lengthways | Ast | mm | 1939 |
| 4.35 | Turning radius | Wa | mm | 1485 |
| Performance data | ||||
| 5.1 | Travel speed, laden/ unladen | km/ h | km/h | 4/4.5 |
| 5.2 | Lifting speed, laden/ unladen | m/ s | 0.022/0.025 | |
| 5.3 | Lowering speed, laden/ unladen | m/ s | 0.034/0.023 | |
| 5.8 | Max. gradeability, laden/unladen | 5/16 | ||
| 5.10 | Service brake type | Electromagnetic | ||
| Electric-engine | ||||
| 6.1 | Drive motor rating S2 60 min | kW | 0.65 | |
| 6.2 | Lift motor rating at S3 15% | kW | 0.84 | |
| 6.3 | The maximum allowed size battery | mm | 265*185*215 | |
| 6.4 | Battery voltage/nominal capacity K20 | 2x12/85 | ||
| 6.5 | Battery weight | kg | 25.5x2 | |
| Addition data | ||||
| 8.1 | Type of drive control | DC | ||
| 10.5 | Steering type | Mechanical | ||
| 10.7 | Sound pressure level at the driver's ear | 74 | ||
Packaging & Shipping
Our Service
EP is no longer just a manufacturer of material handling equipment, but an excellent before, during and after sales service provider. EP is the factoy in China who issue online service system for customers,Including 4 ways as following:1,Online claim system;
2,Online technique system;
3,Online forklift tracking system;
4,Online spare parts order system.
EP's online service and 24 hours reply system ensure that EP customers get the most cost-efficient products.
Global Network
After years of hard work, EP has established a sales network with more than 300 distributors in around 40 countries around the world. The worldwide network provides you quick and professional service.
