4.5ton HELI Rough Terrain Forklift 4 Wheel Drive Forklift Cpcd45
Enhanced comfort through innovative design.
Hydraulic transmission and mechanical transmission types are all available.
Flexible steering and small turning radius, with full Hydraulic Steering System.
We adopt scientific ergonomic method to design H2000 Forklift truck. The operation space has been efficiently enlarged. The rough feeling of the driver has been reduced to the lowest extends.
A variety of domestic and imported engines for you to choose. The emission meets EC and EPA new regulation.
Specially designed container door frame can enter the container for operation. This series forklifts can be equipped with two, or three full free lift mast, and various attachments, according to user's demand.
Enclose cabin is made of assembling plate on overhead guard, high strength overhead is design to ensure the safety.
Operator presence sensing system, the system will cut off the driving force to prevent accidents, when the driver leave the seat during operation.
| General | 1 | Model | CPCD45 | ||||
| 2 | Power type | Diesel | |||||
| 3 | Rated capacity | kg | 4500 | ||||
| 4 | Load center | mm | 500 | ||||
| 5 | Operator type | Seated | |||||
| 6 | Tyre type | Front/Rear | Pneumatic | ||||
| 7 | Number of wheels(X=driven)) | Front/Rear | 2 X /2 | ||||
| Dimensions | 8 | Lifting height | mm | 3000 | |||
| 9 | Free lift height | mm | 150 | ||||
| 10 | Fork size | LxWxT | mm | 1070X150X55 | |||
| 11 | Mast tilt range | F/R | 6/12 | ||||
| 12 | Overall Length(Without fork) | mm | 4180 | ||||
| 13 | Overall width | mm | 1480 | ||||
| 14 | Mast lowered height | mm | 2265 | ||||
| 15 | Mast extended height | mm | 4230 | ||||
| 16 | Overhead guard height | mm | 2230 | ||||
| 17 | Turning radius(Outside) | mm | 2740 | ||||
| 18 | Fork overhang(Wheel center to fork face) | mm | 570 | ||||
| 19 | Min.right angle stacking aisle width (Add load length and clearance) | mm | 3365 | ||||
| 20 | Wheelbase | mm | 2000 | ||||
| 21 | Tread | Front | mm | 1180 | |||
| 22 | Rear | mm | 1190 | ||||
| 23 | Ground clearance | mm | 165 | ||||
| Performance | 24 | Speed | Travel | km/h | 16 | ||
| 25 | Max.Drawbar Pull | Full load/No load | KN | 22 | |||
| 26 | |||||||
| 27 | Max.Gradeability | Full load | % | 18 | |||
| Weight | 28 | Self weight | kg | 6250 | |||
| Wheels | 29 | Tyres | Spec | Front | 8.25-15/13.00x15-18PR | ||
| 30 | Rear | 7.00-12-12PR | |||||
| Brake | 31 | Brake type | Driving brake | Hydraulic | |||
| 32 | Parking brake | Mechanical hand brake | |||||
| 33 | Battery | Voltage/Capacity | V/AH | 12/100 | |||
| 34 | Transmission | Model type | Powershift (Manual) | ||||
| 35 | Stage | FWD/RVS | 2/2 | ||||
| 36 | Operating pressure | Mpa | 19 | ||||
| 37 | Fuel tank capacity | L | 90 | ||||
