Model NO.
CLW5387yc
Fuel
Diesel
Drive Wheel
4×2
Brand
Dongfeng
Models
Small
Usage
Arm Type
Condition
New
Hopper Size
10 Cbm
Hopper Number
for Choice
Material
Carbon Steel
Wheel Base
4500 mm
Engine
Cummins
Horsepower
190 HP
Tire
9.00-25
Logo
as Per Customer′s Request
Warranty
One Year
User Manual
Yes
Transport Package
Naked, Waxed, Bulk Ship, RO-RO
Specification
7560x2500x3350mm
Trademark
CLW
Origin
Suizhou, China
HS Code
8705909090
Production Capacity
500 Unit/Month
Type:
Compactor
Certification:
ISO9000, CCC, TS16949, CE
Volume:
10 Cbm
Emission Standard:
Euro 3
Transmission Type:
Manual
Payload:
9ton, 8ton
Dongfeng 8CBM 10CBM Refuse Collection Swing Arm Truck Garbage Detachable Container Waste Vehicle
Product Description
Swing Arm Garbage Truck is also called garbage collecting truck, garbage transport truck, mainly used in transporting kinds of garbage for municipal sanitatio ,large factories and mines ,etc, especially apply to transport household waste in residential area.
According to loading and unloading type, it is divided into the following categories: dump garbage truck, hook arm garbage truck, compactor garbage truck, swing arm garbage truck, self-loading garbage truck, sealed type garbage truck.
| Drive type | 4*2, New condition, LHD | ||
| Vehicle Main Dimensions | (L x W x H)mm | 7560×2500×3350 | |
| Wheel base (mm) | 4500 | ||
| F/R Axle-Load | 5000/10000 kg, | ||
| Approach/departure angle | 21/18 | ||
| Curb weight | 6645 kg | ||
| GVW | 15800 kg | ||
| Max. driving speed(km/h) | 90 | ||
| Engine | Brand | Cummins ,Diesel ENGINE | |
| Type | 6 -stroke direct injection, 4cylinder in-line with water cooling, turbo-charging and inter-cooling; | ||
| Horse Power(HP) | 190 | ||
| Emission standard | Euro III | ||
| Gearbox | 6 forwards& 1 reverse | ||
| Clutch | Reinforced diaphragm clutch | ||
| Tire | 9.00-20,7 pc including 1 spare tire | ||
| Steering Gear | power steering, hydraulic steering with power assistance | ||
| Upper Body | |||
| Garbage Box Material | Carbon Steel Q235 | ||
| Thickness | Side 3mm ,buttom 4mm | ||
| Garbage Box Volume | 10 CBM | ||
Remarks | 1. Color is optional 2.Customized LOGO painting as per customer request | ||
