LY-490-250 rear differential axle
Universal, Industrial, Power Tools, Electric Wheelchair Motor
Low Speed
Permanent Magnet
Control, Driving
Protection Type
4
Brush
Differential Motor
ISO9001, CCC
Lunyee
Ly-490-250
DC Geared Motor
24V/36V
250W/180W
3000rpm
230-250rpm
10-20A
17.75:1
Electric Motors for Vehicles
490mm
IP54
68mm
LUNYEE
Standard Export Pacakge
China
8501310000
Product Description
48v motorized 24v 180w 250w electric tricycle atv rear axle differential wheel and axle
This dc-motor drive rear-axle is composed of a permanent magnet DC motor and a gearbox differential.
It is characterized by small turning radius and high sensitivity. It is suitable for three-wheel and four-wheel electric vehicles that require rear drive.
This electric rear differential axle has a wide range of applications.
It is widely used for go cart, mini robot, sweeper, mainstream travel trailer, Engineering vehicles, Special vehicles, medical facilities, mobility scooter for old people, cleaning machines, electric wheelchairs, warehouse transport push cart, etc.
24v 250w Rear Differential Axle
Type | LY-490-250 |
Voltage | 24V |
Power | 250W |
On load Current | 10-20A |
Max Torque | ≥55N.m |
Output speed | 230-250RPM |
Ratio | 17.75:1 |
Max Load | 100KG |
Motor Diameter | 68mm |
Alex length | 490mm |
How to chooes suitable rear differential axle kit ?1. Confirm the application
2. Confirm the motor voltage, power and speed you want
3. Confirm rear axle length (can be customized)
4. We also provide matching driver system if needed.
4. We also provide matching driver system if needed.
