HWE-4F40
Li-ion Battery
LFP
Yes
Medium
1 Year
Over 3000 Times
25A
40A
HWE
Standard Air Transport Packaging
182*130*195mm
China
8507600090
Product Description
Prouduct Description
Features of LiFePO4 Battery
1,Longer Cycle Life:Offers up to 20times longer life and five times longer fioat life than lead acid battery, helping to minimize replacement cost and reduce total cost of ownership.
2,Lighter Weight:About 40% of the weight of a comparable lead acid battery. A 'drop in' replacement for lead acid batteries.
3,Higher Power:Delivers twice power of lead acid battery,even high discharging rate,while maintaining high energy capacity.
4,wider Temperature Range:-20ºC-60ºC.
5,Superior Safety:Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact,overcharging or short circuit situation.
6,Increased Flexibility:Modular design enables deployment of up to four batteries in series and up to batteries in parallel.
Howell Energy Co., Ltd is one of the leading battery manufacturer in China mainland, who focus on LiFePO4, Li-polymer, Li-ion, NI-MH, and NI-CD rechargeable batteries, including PCM and the total power system solution, our batteries passed by CE, ROHS and CB certifications.
Our company has over 20 years experience in battery R&D, producing and the overseas marketing. In our ISO 9001:2008-certified factories, which span a total of 120,000 m2, we can turn out over 6,000,000Ah monthly production capacity. With professional R&D team, experienced workers and advanced equipments, we are determined to provide you high-quality battery.
Customers feedback:
Q1. Can I have a sample order for Battery?
A: Yes, we welcome sample order to test and check quality.
12v 100ah lifepo4 battery
Q2. What about the lead time?
A:Sample needs 5-10 days, mass production time needs 25-30 days.
12v 100ah lifepo4 battery
Q3. Do you have any MOQ limit for Battery?
A: Low MOQ, 1pc for sample checking is available
12v 100ah lifepo4 battery
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by UPS, TNT... It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
12v 100ah lifepo4 battery
Q5. How to proceed an order for Battery?
A: Firstly let us know your requirements or application.Secondly We quote according to your requirements or our
suggestions.Thirdly customer confirms the samples and places deposit for formal order.Fourthly We arrange the production. 12v 100ah lifepo4 battery
Q6. Is it OK to print my logo on Battery?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
12v 100ah lifepo4 battery
Q7: Do you offer guarantee for the products?
A: Yes, we offer 1-2 years warranty to our products. 12v 100ah lifepo4 battery
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new batteries with new order for small quantity. For defective
batch products, we will repair them and resend them to you or we can discuss the solution including re-call according
to real situation.12v 100
| Electrical Characteristics | Nominal Voltage | 12.8v |
| Nominal Capacity | 40Ah | |
| Energy | 512Wh | |
| Internal Resistance | ≤80mΩ | |
| Cycle Life | >3000 cycles @ 1C 100% DOD | |
| Months Self Discharge | <3% | |
| Effciency of Charge | 100%@0.5C | |
| Effciency of Discharge | 96-99%@1C | |
| Standard Charge | Charge Cut-off Voltage | 14.6±0.1V |
| Charge Mode | 0.2C to 14.6V,then 14.6V,charge current to 0.02C(CC/CV) | |
| Charge current | 8A | |
| Max charge current | 25A | |
| Standard Discharge | Continuous current | 20A |
| Max discharge current | 40A | |
| Discharge Cut-off Voltage | 10V | |
| Environmental | Charge Temperature | 0 ºC to 45 ºC (32F to 113F) @60±25% Relative Humidity |
| Discharging Temperature | -20 ºC to 80 ºC (-4F to 140F) @60±25% Relative Humidity | |
| Storage Temperature | 0 ºC to 40 ºC (32F to 104F) @60±25% Relative Humidity | |
| Mechanical | Plastic Case | ABS |
| Dimension | 182*130*195mm | |
| Terminal | connector | |
| Weight | 5.7kg |
