SOLAS Platform Type Totally Enclosed Lifeboat
Marine Lifesaving
16-150 Persons
CE, CCS
FRP
CCS, Ec, ABS, BV, Rmrs, Rina etc
Solas, Imo Msc, Lsa
Diesel Engine
Platform Type Lifeboat
8 Knots
Not Less Than 24 Hours
International Orange
Adult
Life Boat
Marine Lifesaving
HY
Naked in Container
SOLAS MED Platform Type Totally Enclosed Lifeboat
China
Product Description
Solas Approved Fire Resistant Totally Enclosed Lifeboat Platform Type Life Boat for Offshore Oil Platform
SOLAS Offshore Oil Platform Type Fire Resistant Totally Enclosed Lifeboat is a model aboard from the stern port designed and manufactured in accordance with The latest specification of SOLAS and international standards.
It can fall into the water through the slideway (on ship or oil platform) and keep the passenger in the
Boat, ensure quick and safe escape.
Boat Body material:Fire-protected type FRP
Certification:CCS/BV/ABS/EC
Life boat Details
| Davit load: | Max. 65KN |
| Winch load: | Max. 58KN |
| Lowering load of davit: | Min.25KN, Max.65KN |
| Lowering speed: | S=(0.4+0.02×H)(Full load boat) 0.6-1.0 m/s |
| Lowering speed of wind: | 80-100m/min |
| Hoisting speed: | ≥10m/min(for life boat) ≥36m/min(life boat &rescue boat) |
| Hook span: | 4.70 m |
| Installation height to waterline | ~6.5 m |
Type list life boat parameter
| Size | Capacity | Height | Speed | Weight | Full Weight |
| 4.9*2.18*0.7m | 16P | 3m | ≥6 | 2580/2870kg | 3900/4190kg |
| 5.2*2.35*3.07m | 16~20P | 3.07m | ≥6 | 2780/3120kg | 4100/4440kg |
| 5.9*2.36*3.1 | 26P | 3.1M | ≥6 | 2774/3120kg | 4919/5265kg |
| 6.0*2.32*0.86m | 20P | 3.1m | ≥6 | 3000/3300kg | 4650/4950kg |
| 6.6*2.75*3.1m | 30P | 3.1m | ≥6 | 3520/3860kg | 5995/6335kg |
| 6.75*2.75*0.76m | 32P | 3.1m | ≥6 | 3530/3840kg | 6170/6480kg |
| 7.5*2.75*3.2m | 36P | 3.2m | ≥6 | 4140/4480kg | 7110/7450kg |
| 8.5*2.95*3.2m | 50P | 3.2m | ≥6 | 4560/4900kg | 8685/9025kg |
| 10.9*2.95*3.3m | 67P | 3.3m | ≥6 | 6508/6919kg | 12036/12446kg |
| 14.5*3.25*3.4m | 90P | 3.4m | ≥6 | 9135kg | 16560kg |
| Note: FC: CARGO VERSION FF: TANKER VERSION | |||||
In addition to the fully enclosed lifeboat, the fireproof lifeboat is also equipped with water supply equipment and air supply device. It is generally mounted on ships with fire risks such as oil tankers and gas carriers. If necessary, it can supply air (people and hosts) consumed within 10 minutes. In order to escape from the ocean space destroyed by fire, the lifeboat is equipped with high-pressure air. container.
In order to prevent the surface of the lifeboat from being burned by fire and the temperature inside the lifeboat from rising sharply during a fire at sea, the water pump installed on the lifeboat is put into operation and sprays water on the canopy. Use a water spray pipe to suck up seawater from the bottom of the lifeboat, and the surface of the lifeboat is covered with a water curtain.
