Marine Totally Enclosed Lifeboat with Davit
Comply with the requirements and rules of SOLAS and amendment 1996, LSA Code, MSC.218(82), MSC.272(85), MSC.320(89) & MSC.81 (70), MSC. 226(8 MSC.274(85), MSC.321(89).
1. Boat body material: fire-pretended type FRP;
2. Fitted with stainless release mechanism and launched or recovered by falls;
3. it can self-righting by itself when capsized;
4. The surface for walking is the antiskid;
5. Equip a manual pump remove the pending in the boat;
6. Rubber fender is fitted around the boat;
7. Running time of rescue boat when full-loaded & full-speed is more than 24 hours.
8. Speed(full load):>6knots
9. Have tanker version and cargo version for choose.
Specification of Marine Totally Enclosed Lifeboat with Davit
Type | Dimension(m) | Persons | Hook Distance | Depth | Craft weight | Full load(kg) | Speed | Engine |
50C/F | 5*2.3*2.84 | 25 | 4.50m | 1.00m | 2115/2457 | 4260/4602 | ≥6 | 380J-3/YANMAR3JH25A/ BUKH DV24 RME
|
57C/F | 5.8*2.32*3.1 | 33 | 5.30m | 1.15m | 2284/2262 | 5006/5344 | ≥6 | |
65C/F | 6.6*2.32*3.1 | 40 | 6.10m | 1.15m | 2861/3136 | 6161/6436 | ≥6 | |
75C/F | 7.6*2.78*3.1 | 55 | 7.10m | 1.20m | 3000/3300 | 7537/7857 | ≥6 | 380J-3/YANMAR3JH30A/ BUKH DV29 RME |
80C/F | 8.0*2.96*3.1 | 65 | 7.60m | 1.20m | 3125/3500 | 8487/8862 | ≥6 | |
85C/F | 8.5*3.3*3.3 | 90 | 8.10m | 1.25m | 4361/4691 | 11786/12116 | ≥6 | |
93C/F | 9.3*3.45*3.35 | 106 | 8.9m | 1.30m | 5160/5461 | 13810/14220 | ≥6 | 380J-3 |
99C/F | 10.05*3.8*3.45 | 120 | 9.4m | 1.25m | 6050/6500 | 15950/16400 | ≥6 | N485J-3/BUKH DV48RME |
102C/F | 10.28*3.5*3.35 | 130 | 8.95m | 1.30m | 5658/5960 | 15375/15775 | ≥6 | 380J-3 |
117C/F | 11.7*3.55*3.4 | 150 | 11.30m | 1.30m | 5317/5617 | 18190/18600 | ≥6 | 380J-3 |
Freefall Lifeboat
| Type | Size | Capacity | Height | Speed | Weight | Full Weight |
| 49FC/FF | 4.9*2.18*0.7m | 16P | 3.0m | ≥6 | 2580/2870kg | 3900/4190kg |
| 52FC/FF | 5.2*2.35*3.07m | 16-20P | 3.07m | ≥6 | 2780/3120kg | 4100/4440kg |
| 59FC/FF | 5.9*2.36*3.1m | 26P | 3.1m | ≥6 | 2774/3120kg | 4919/5265kg |
| 60FC/FF | 6.0*2.32*0.86m | 20P | 3.1m | ≥6 | 3000/3300kg | 4650/4950kg |
| 66FC/FF | 6.6*2.75*3.1m | 30P | 3.1m | ≥6 | 3520/3860kg | 5995/6395kg |
| 675FC/FF | 6.75*2.75*0.76m | 32P | 3.1m | ≥6 | 3530/3840kg | 6170/6480kg |
| 75FC/FF | 7.5*2.75*3.2m | 36P | 3.2m | ≥6 | 4140/4480kg | 7110/7480kg |
FC: cargo version FF: tanker version
Our Certification
Welcome to contact us for more information if you are interested in Marine Totally Enclosed Lifeboat, Freefall Lifeboat or Rescue Boat.
