Model NO.
1031.401
Travel Height
600mm
Transport Package
Wood Carton
Specification
CE
Trademark
SAFEDOOR
Origin
Hangzhou, China
Production Capacity
1000PCS/Month
Position:
Vehicle Fence
Material:
Steel
Function:
Obstruction
Upright Post:
168mm
Post Fixation:
Embedded Type
Degree of Distortion:
Rigid Barrier
Automatic BOLLARD barrier
Features:
*Easy installation
*High security for optimal protection
*Control mode: push button, card reader, remote control, loop detector
*Safety signs: Illuminated ring, reflective bands, LED warning light zipper, loop detector system, traffic lights
*It integrates the guide rails and is designed to work without wear or tear for very limited maintenance
*A guiding ring of thick plastic eases the travel of the bollard up and down reducing friction and noise
Technical parameter:
| Specification | 1031.401 | 1031.402 | 1031.403 | 1031.404 |
| Operating mode | Semi-automatic | Pneumatic & Hydraulic | Pneumatic & Hydraulic | Pneumatic & Hydraulic |
| Column diameter(mm) | 168 | 220 | 273 | 320 |
| Power supply(V) | 220/380 | |||
| Travel height (mm) | 600/700 | |||
| Protection (IP) | 66 | |||
| Resistance against impact (Joule) | 60000 | |||
| De-watering requirement (L/min) | 5 | |||
| Running speed(s) | 5~9 | |||
| Ambient temperature(ºC) | -20~+60 | |||
| Operation frequency(/h) | 12 | |||
| Material | Stainless steel | Stainless steel or steel tube with plastic-sprayed surface (Red/Yellow/Blue/Black) | ||
| Illuminated ring | / | Optional | ||
| Reflective bands | Optional | |||
