HQCY160
24 Hours Every Day of Technology and Parts Service
12 Months
Adjustable
Powered Pallet Truck
Diesel Engine
10T - 18T
Diesel
>500mm
>5000mm
New
Cummins or Weichai
Weichai or Cummins 162kw
Haiqin
by Container
CCC, ISO, SGS
Shandong, China
84271090
Product Description
1, Specifications :
| 1 | Rated Load Capacity | kg | 16000 | |
| 2 | Centre Distance | mm | 1200 | |
| 3 | Qty of Tyre(Front/Rear) | / | 2/2 | |
| 4 | Lifting Height | mm | 3000 | |
| 6 | Mast Tilt Angle(Front/Rear) | drg | 6/12 | |
| 7 | Overhead Guard Height | mm | 3515 | |
| 9 | wheel base(Front/Rear) | mm | 2400/2400 | |
| 12 | Max Raising Speed(Full Loading) | mm/s | 150 | |
| 13 | Moving Speed(Full Loading) | km/h | ≤15 | |
| 14 | Max Grade Ability(Full Loading) | % | ≤20 | |
| 16 | Tyre Size( Front/Rear) | / | 23.5-25-24PR | |
| 17 | Tyre Pressure | Mpa | 0.6 | |
| 18 | Dead weight | Empty load | mm | 19200 |
| 19 | Engine | Model | / | WEICHAI 162KW/2200 or Cummins |
| 20 | Dimension | Length(Fork is lay) | mm | 8530 |
| 21 | Width | mm | 2890 | |
| 22 | Height | mm | 3515 | |
2,, Certificate of Haiqin Machinery:
3, Warranty and Service.
HAIQIN Forklift has One Year Warranty.
During Warranty, if there is any part broken because of quality problem(except easy-damaged parts), send us detailed pictures and video, then we will send good/ new parts for your replacements.
Choose HAIQIN, and then better after-service will be guaranteed.
Contact us right now for more information! Online 24 hours a day!
