Motor for Elevator Door Operator Parts
Motor for Door Operator
1. The motor is compact in structure, small in size and light in weight.
2. The use of high-precision reduction gear effectively reduces noise and improves service life.
3. Using 200-500 mesh high-precision photoelectric encoder to achieve accurate positioning.
4. The rotor adopts paint dropping process to improve the insulation performance of the motor.
5. With mechanical self- locking function.
PARAMETER
| Model | ZY622430-RV6215S | |||||
|---|---|---|---|---|---|---|
| Dimensions(mm) | 97x87x201.5 | Rated Voltage(V) | 24 | Rated Current(A) | 5.0 | |
| Rated Wattage(W) | 38 | Rated Torque(N·m) | 2.0 | Rated Speed(rpm) | 180 | |
| Poles | 2 | Working Type | 40%(S3 on 6s off 9s) | Classification | IP22 | |
| Insulation Grade | F | Encoder Classification | G | |||
| Pulley | Tooth Outline | 5M | ||||
| Tooth Number | 28/19/16 | |||||
| Width of pulley(mm) | 17/13 | |||||
| Note: | 1.Installation size:50x30mm 2.Matching pulley:HTD5M-16,HTD5M-26,HTD8M-22 3.F grade insulation grade, IP65 protection grade 4.Insulation Resistance≥100MΩ(Cold) 5.The whole machine pressure resistance 500V, 1min, no breakdown 6.No-load noise value≤50dB 7.No-load level & vertical vibration≤0.45mm/s | |||||
