Popular Item Zoomlion 200 Ton Big Crawler Crane Zcc2000h

As a leading Chinese machinery and truck exporter, we have a professional experience of 8years in this field. Besides our trucks of high quality, our international sales team will also provide you excellent logistics service and after-sales service.  We will always do our best to solve all the problems and put our customer's interests in the first place.

Contact :Allan


hot sale zoomlion 80ton 100t 180t 200t crawler crane


Item	Unit	Value	Remarks
Max. lifting capacity × radius			t × m	80×4
Max. lifting capacity on fixed jib			t	7
Max. lifting capacity of luffing jib			t	15
Main boom length			m	13 - 58
Fixed jib length			m	6 - 18
Max. length of main boom with fixed jib			t	49+18
Luffing jib length			m	16m-34m
Max. main boom +max. luffing jib			m	43.5m+34m
Derricking angle			.	30 - 80
Fixed jib angle			.	10, 30
Max. rope  speed of winches		Hoisting winch 1	m/min	125/110	With optional free-fall function
		Hoisting winch 2		125
		Derricking winch		93
Slewing speed			rpm	0-2
Traveling speed			km/h	0-1.57
Max. gradeability			%	30	With basic boom and counterweight over front
Ground pressure			Mpa	0.083
Deadweight			t	72.8	With basic boom
Crane counterweight			t	27
Overall dimensions(L × W × H)			m	13500×5000 (3400) ×3200	With A-frame and main boom pivot section
Engine		Model		WP10.270N	Weichai  Power
		Rated power / rotational speed	kW/r/min	199/1900
		Max. output torque /rotational speed	Nm/r/min	1270/1200-1500
		Exhaust emission		National StageII
Distance between track center × crawler contact length × crawler width			mm	2600 ×5440×800	Crawler carrier retracted
				4200 ×5440×800	Crawler carrier extended
Noise	Noise level outside operator's cab during operation		(dB)	≤107
	Noise level in operator's cab during operation			≤79
