XP60
Video Technical Support, Online Support
1 Year
Adjustable
Diesel Forklift
Diesel Engine
5 Ton
Diesel
500mm
90-3000mm
New
2205mm
500mm
2374mm
90mm
3000mm
4205mm
2285mm
230X85X1650mm
2750mm
2520mm
AC Power
Fork Positioner
AC Controller
150mm
AC Motor
Forklift
Nude Packing
2750*1394*2285mm
Jiangsu, China
8427209000
Product Description
HELI5 ton Battery Electric Forklift CPD50 with Good Price
Product Overview
11. Type: XP60
2. Load: 6000 kg
3. Max Lifting Height: 205mm
4. HS Code: 8427109000
5. Certificate: CE/SGS/ISO9001
Product Paramenters
Identification | 1 | Product model | XP60 | |
2 | Drive unit | Electric | ||
3 | Operate type | Standing | ||
4 | Load capacity | Q kg | 6000 | |
5 | Load center | C mm | 850 | |
6 | Load distance, Center of drive axle to fork back | X mm | 248 | |
7 | Wheelbase | Y mm | 2205 | |
Weight | 1 | Truck weight (without battery) | kg | 1650 |
Wheel | 1 | Tires | Polyurethane | |
2 | Drive wheels size | mm | Φ248×75 | |
3 | Loaded wheels size | mm | Φ125×50 | |
4 | Balance wheels size | mm | Φ150×50 | |
5 | Wheels number, front/rear(x=driven wheels) | 1x-4/8 | ||
6 | Tread ,front | mm | 687 | |
7 | Tread ,rear | mm | 470 | |
Dimensions | 1 | Height, mast lowered | h1mm | 1465 |
2 | Lift height | h3mm | 250 | |
3 | Forks height, lowered | h5mm | 130 | |
4 | Height of tiller in drive Position(max/min) | h6mm | 1405/1192 | |
5 | Overall length | L1mm | 2735 | |
6 | Length to face of forks | L2mm | 1085 | |
7 | Overall width | b1mm | 900 | |
8 | Fork dimensions | s/e/lmm | 230/85/1650 | |
9 | Maximum forks width | b3 mm | 700 | |
10 | Minimum ground clearance(unload) | M mm | 32 | |
11 | Aisle width for pallets 800x1200 lengthways | Ast mm | - | |
12 | Turning radius | Wa mm | 2536 | |
Performance | 1 | Travel speed loaded/unload | km/h | 3.6/4 |
2 | Lift speed loaded/unload | mm/s | 28/40 | |
3 | Lowering speed loaded/unload | mm/s | 45/40 | |
4 | Max grade ability loaded/unload | % | 2.5/8 | |
5 | Service brake | Electromagnetic brake | ||
Electric Motor | 1 | Drive motor rating | kw | 3 |
2 | Lift motor rating | kw | 3 | |
3 | Battery voltage/capacity | V/Ah | 24/360 | |
4 | Battery weight | kg | 340 | |
Others | 1 | Control unit type | Mosfet control | |
2 | Sound level | dB(A) | <70 | |
