SJZ0.5
Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
Scissor Lift
Middle-Level
Self-propelled
DC
Moving
GS, CE, ISO 9001
500kgs
fusen
Pallet
2560 x1195x 2326
China
8427900000
Product Description
Self-propelled Electric Scissor Lift (500kg, 7m ~14m)
Product Description:
1. New design,national patented products,Unique Transformers series appearance.
2. Folding guardrails conforms with international safety standard, which can effectively
protect the safety of high-altitude operation.
3. The operator can control the movement,lifting and descending to realize continuous
operation at high altitudes.
4. Installed with emergency stop switch to protect personal safe
Technical Specification:
Product Description:
1. New design,national patented products,Unique Transformers series appearance.
2. Folding guardrails conforms with international safety standard, which can effectively
protect the safety of high-altitude operation.
3. The operator can control the movement,lifting and descending to realize continuous
operation at high altitudes.
4. Installed with emergency stop switch to protect personal safe
Technical Specification:
| Model | Unit | SJZ0.5-7 | SJZ0.5-9 | SJZ0.5-11 |
| Capacity | kg | 500 | ||
| Max.Lifting height | mm | 7000 | 9000 | 11000 |
| Min.Plate height | mm | 1290 | 1558 | 1560 |
| Plate size (LxW) | mm | 1830x1000 | 2100x1140 | |
| Unfolding size | mm | 1860x2195 | 2250x2895 | |
| Lifting motor | v/kw | 60/2.2 | ||
| Motor | v/kw | 60/1.2 | ||
| Voltage | v | 60 | ||
| Drive speed | km/h | 4-6 | ||
| Max.gradeability | % | 10-15 | ||
| Battery | v/Ah | 60/85 | ||
| Charger | v/Ah | 60/8 | ||
| Overall length | mm | 2560 | 2957 | |
| Overall width | mm | 1195 | 1335 | |
| Overall height | mm | 2326 | 2594 | 2596 |
| Net weight | kg | 1350 | 1490 | 1580 |
