UB500-18GM-E5-V1
Large Range and High Frequency Ultrasonic Sensor
Switch Type
Integration
High
Surface Wave Probe
Liquid
Direct Reflection Type
IP67
CE
Customized
30 to 500mm
About 380kHz
10 to 30VDC,Ripple10%Ss
V1 Connector(M12*1),4-Pin
1 Switch Output E5,PNP No/Nc, Programmable
Brass,Nickel-Plated
Winston/OEM/Neutral
Carton Packing
CE
China, Zhejiang, Wenzhou
90330000
Product Description
M12 Connector Ultrasonic Sensor Long Distance (UB500-18GM-E5-V1)
PS:If you can't find the exact type of your product.Please don't rush to go away.Contact me and your questions will be replied ASAP.Thank you for your time.
Our Services
Trade Information
| UB500-18GM-E5-V1 | ||||||||
| Technical data | ||||||||
| Sensing distance | 30…500mm | |||||||
| Adjustment range | 50…500mm | |||||||
| Unusable area | 0…30mm | |||||||
| Standard target plate | 100mm×100mm | |||||||
| Transducer frequency | About 380kHz | |||||||
| Response delay | About 50ms | |||||||
| Indicators/Operating means | ||||||||
| LED blue | Power on | |||||||
| LED yellow | indication of the switching state Flashing: program function object detected | |||||||
| LED red | permanently red: Error Red,flashing:program function, object not detected | |||||||
| Electrical specifications | ||||||||
| Operating voltage UB | 10…30VDC,ripple10%ss | |||||||
| No-load supply current | ≤45mA | |||||||
| Input | ||||||||
| Input type | 1 TEACH-IN input Operating distance A1: UB+1V,operating distanceA2:+6… + UB Input impedance:>4.7KΩ TEACH-IN programmable pulse : ≥1S | |||||||
| Output | ||||||||
| Output type | 1 switch output E5,PNP NO/NC, programmable | |||||||
| Rated operational current | 100mA,short-circuit/overload protected | |||||||
| Default setting | Switching point A1:70mm Switching point A2: 800mm | |||||||
| Voltage drop | ≤ 3V | |||||||
| Repeat accuracy | ≤ 1% | |||||||
| Switching frequency f | ≤ 8 HZ | |||||||
| Mechanical specifications | ||||||||
| Protection grade | IP67 | |||||||
| Connection | V1 connector(M12×1),4-pin | |||||||
| Material Housing | brass,nickel-plated | |||||||
| Transducer | epoxy resin/hollow glass sphere mixture; foam polyurethane,cover PBT | |||||||
