HDWS-772M161M1
1year
1year
Car, SUV, Truck, Agricultural Vehicles, Engineering Vehicles, Sightseeing Car, RV, Forklift, Harvester, Corn Machine
ABS+PC
LCD Matrix
Air Plug
Night Vision, Waterproof, Dustproof, Shockproof
720ptvl
CCD
IP69K
IP69K
10g
120 Degree
DC10~32V
VEISE
Gift Box
CE, FCC, ISO9001: 2000, RoHS, E-MARK
China
8528591090
Product Description
720P Wireless Reverse Camera System
Model:HDWS-772M161M1
HD wireless monitor
1024RGBX600 high resolution
Open transmission distance 150 meters
Automotive industrial grade DSP
Graphical OSD menu
600cd/M2 high brightness
U-shaped + bilateral fastening support
DC8~32V operating voltage
Reverse polarity, load dump pulse voltage suppression protection
720P 2.4GHz digital wireless camera
Effective pixels 1280(H) X 960(V)
Heat-dissipating aluminum alloy shell
Nitrogen-filled, anti-fog, waterproof IP69K
IR-CUT filter and 6pcs IR LED
DC8~32V operating voltageFeaturesHIGH QUALITY - The HD wireless monitor is made of durable ABS material with a removable sun visor, the wireless camera aluminum alloy housing is waterproof and IP69K rated to resist high pressure water washdown. The working temperature of automotive industrial grade DSP is -40°C to +85°C, and it is resistant to impact and corrosion. Graphical OSD menu to set the screen mirroring and front image, reversing ruler, trigger priority application functions.Built-in external power reverse connection protection and load shedding pulse voltage suppression circuit.
SUPER VISION - HD wireless monitor uses 7 inch IPS screen, high resolution 1024RGBX600, wide viewing angle and bright colors. The 1080P wireless camera uses an effective pixel 1920(H) X 1080(V) image sensor and 6 night vision infrared LEDs.IR-CUT filter corrects the color cast during the day and improves the brightness at night
WIDE APPLICATION - HD wireless camera monitoring system is free of working voltage DC8-32V, easily and quickly installed in trucks, agricultural equipment vehicles, horse trailers, farm CCTVs, forklifts, street sprinklers, engineering vehicles, home baby monitors, ranch delivery room monitoring vehicles, ambulances, etc.ParameterSystem model HDWS-772M161M1 HD Wireless Monitor (MWHD-772M) Color LCD screen 7-inch IPS screen Wireless reception Built-in 2.4G wireless receiver Picture mode Single screen switching + 2 split working frequency 2400~2483.5MHZ Receiving sensitivity ≤-86 dB Receiving distance Open ≤100m Multi-frequency automatic frequency hopping channel code ion 80 Resolution 1024(H) X 600(V)dot Color system PAL/NTSC (AUTO) Brightness(cd/m2) 600 Load dump DC24+174V(Td350mS) 5pulses Vibration resistance level 5G (conforms to GB-T2423056-2006 standard) Working temperature -20ºC to +70ºC Storage temperature -30ºC to +80ºC Working voltage DC8-32V Dimensions (L x W x T) (218 x 150 x 54mm) HD Wireless Waterproof Camera(CWHD-161M) Image sensor 1/3.7 Color DSP Wireless transmission Built-in 2.4G digital wireless transmitter Transmit power 18dBm Launch distance Open area≤100m Resolution 720P Effective pixels 1280(H) X 960(V) Viewing angle 130° Infrared distance 15 meters Shell material Aluminum alloy Waterproof rating IP69K Working voltage DC8-32V Working temperature -20ºC to +60ºC Storage temperature -30ºC to +70ºC Vibration resistance level 5G (conforms to GB-T2423056-2006 standard) Dimensions 72(W) x 141.5(H) x 120(D) mm
