Environmental Car Spray Booth Chinese Car Paint Booth Manufacturer CE Auto Spray Booth for Sale





Products Description

Model No.EZ-DB 100F
Inside Dimension	6900*4000*2800 mm(L*W*H)
Outside Dimension	7000*5500*3500 mm(L*W*H)
Front Door	2800(W)*2600(H) mm, 3 pieces folding doors,frame cover, with two sets of pressure locks.
Service door	650*1800, with two sets of pressure lock which will automatically open when the pressure inside is over the limit.
Basement	Galvanized steel, 300mm high, quadrate steel support,3 rolls grilles made by flat bar and twisted steel, gavlanzid, 2 rows diamond plate, galvanized, 3 ramps,900*2000 mm/pc.
Environmental System	G3 grade glass fiber floor filter, exhaust active carbon filter.
Generator cabinet	Intake from back upper, exhaust from back upper, white coated steel outside covered, galvanized steel inside, filled with heat preservation material inside.
Intake&Exhaust System	Air inlet: 2*4kw Double-intake centrifugal fan, power:4KW, air capacity is 29000 m3/h; Air Outlet: 1*7.5KW turbo fan, power: 7.5KW, air capacity: 25000m3/h.;
Lighting System	Ceiling Lights: 8Units×4Pcs=32Pcs×36W, Side Lights: 10Units×2Pcs=20Pcs×36W, with electronic ballasts, lighting boxes open outside, illumination≥1200Lux.
Heating System	RIELLO RG5S diesel burner, stainless steel heat exchanger, pneumatic damper actuates from spraying to baking cycle. Max. heating productivity: 260000Kcal/h.
Purification System	G3 grade, Air Inlet pre filter, EU5/F5 high efficiency filter (ceiling filter), G3 grade glass fiber floor filter, exhaust active carbon filter.
Controlling System	Spraying, heat spraying, baking, time setting, lighting switch, failure indicator, thermostat, power supply switch, emergency stop, hour meter, temperature limit controller, pressure gauge.
Power	43 KW
Cabin System	Wallboard		Rock Wool material, tongue and groove interlock construction, thickness: 50mm, 0.5mm steel plate.
	Basement		Galvanized steel assemble, 300 mm high, quadrate steel support, full grilles made by flat bar and twisted steel, galvanized; 3 Pcs ramps, each size: 900X2000MM(WXL).
	Inlet Fan		Double-intake belt centrifugal fan, Capacity: 14500m³/h each.	Outlet Fan	Double-intake belt centrifugal fan, Capacity: 18000m³/h.
			Power: 4 KW		Power: 5.5 KW
			Quantity: 2 sets		Quantity: 1 set
	Ducting		4 meters exhausted air duct, one flop damper, one weather hood, one anti-bird mesh.

Pictures of our spray booth

Front View


The Ceiling


The inside View--for basement, we also can do full girlles, 3 grilles in the middle.


Production machine--high technology machine makes sure precise production



Introduction
Captain Auto Equipment Co.,Ltd is a professional leading factory in China, who is specializing in manufacture kinds of paint spray room system. And also offering full garage equipments, such as

Car care equipment.

Car spray&baking room system

Bus spray&baking room system

Furnitue spray&baking room system

Industrial painting&baking room system

High temperature baking room system

Customized spray&bake booth and Offer car spray baking booth accossories


Services We Supply

Customized service, More Than 90% Of Our Spraying Booth Is Customized.

1. We can design the machines according your requirements. At the same time, our engineers will give you our professional suggestions. The draw we made according to our buyer's need.


2. We can give you free technical support and consultation such as design your factory, make the factory layout drawing and so on.

After-sales service

1. Our fast and professional after service engineer team can go to your factory and install the machine, give you the operating guidance, and train your employees until they can operate the machine well.

2. We often ask feedback and offer help to our customer whose machine have been used in their factory for some time.

3. We provide 2 years warranty.


Captain Advantages

*The same price higher quality, the same quality lower price! ! !

*2 years quality warranty! ! !

*Fast and stable supply capability! ! !
From the picture you can see we have engough stock to ensure fast delivery!


*Personalized design to meet customer various needs! ! !


Competitive Price and High Quality Spraying Booth with Perfect Service Is From Here.
